CNC Aluminum Profile Window Door Double Head Cutting Saw

Name: CNC Aluminum Profile Window Door Double Head Cutting Saw
Brand: tool-buy.com
SKU: 738771455
Availability: InStock
Rating: 4.3 (93 reviews)

Price:	US $ 30000-31000/Piece
Trade Terms:	FOB,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T

Contact Supplier

Jinan Parker Machinery Co., Ltd.

Showroom Product Company Profile

Aluminium Automatic CNC Double Head Cutting Saw Machine

Model: LJZ-CNC-E500
Feature:

It has large cutting range, hi-efficiency and perfect safe guards. It is suitable for large scale production.
The structure is strong and of excellent rigidity and reliability, so it is impossible to be out of shape.
The hi-quality imported special hard-metal saw makes cutting more precision.
The main shaft with hi-precision makes the saw operating stable and the cutting surface smooth.
The gas-liquid damping cylinder realizes smooth feeding and steady moving.
The imported guide rails and the linear motion pair can realize high precision and accurate location.
The two-way location-and-clamping features high precision and steadiness.
The well-sealed safeguard of saw blade prevents the cutting bits from flowing everywhere.

Parameter:

Voltage:	380V 50HZ
Power:	5.9KW
Air pressure:	0.5-0.8MPa
Air consumption:	200L/min
Blade specification:	(standard size)
Cutting length:	400mm-4200mm
Cutting width:	Max.135mm
Cutting height:	Max.300mm
Cutting angle:	45° 67.5° 90°
Repeat locating length error:	0.2mm
Cutting angle error:	4 degree
Surface plainness:	0.1mm
Surface roughness:	Ra12.5m
Overall dimension:	5500mm1750mm1990mm

PARKER IS DEVELOPING WITH THE WORLD.

Parker was founded in 2003, since the entry into the window door curtain wall machinery manufacturing field, peck with the best team and most stringent manufacturing standards, has been committed to the global supply of machinery and the best service. Today, with more than 300 employees, Parker Industrial Park covers an area of 70000 square meter, Parker has become Chinese and even the world's window door curtain wall and insulating glass high-end machinery manufacturing base.

FAQ

Q: How can I get the best machine for our business?

A: Just let us know your cutting material, size, thickness, and working area needed, we will suggest the most suitable machine and professional solution.

Q: When can we arrange shipment?
We usually arrange shipment in 15 days after getting deposit, but customized machines should be more than 25 days.

Q: This is my first time using this kind of machine, is it easy to operate?
A: Of course the machine is easy to operare. We will send you the English version user manual and install video which shows how to assamble and use the machine clearly, almost all the customers can operate the machine easily. No need to worry about this, after all, Parker will always be here to help!

Q: If the machine has problem in my place, how could I do?
A: Usually there won't be any problem under "normal use" as per the user manual. But in case you have any problem, our professional after-service team will provide you any support you need any time!

B.We can send you free components to you if your machines are in guarantee time.
C.We can send our engineers to repair your machines.

Q: This machine is not suitable for me, do you have more models available?
A: Sure, in order to meet different customers' different requirments, we reserched many other different machines.
CNC machining center

Aluminum window door/ curtain wall making machine

UPVC window door making machine

Insulating glass making machine

If need more details or video, please kindly contact below:

Contact	Carina Zhang
Company	PARKER MACHINERY CO.,LTD,CHINA
Mobbile	+86-15106958367
Website	http://www.parker-chn.com
Industrial Park add:	Mingjia West Road, Qihe, Shandong, China

Prod Model:	LJZ2-CNC-E500
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Cutting Length:	400mm-4200mm
Cutting Width:	Max.135mm
Cutting Height:	Max.300mm
Cutting Angle:	45 67.5 90 Degree
Repeat Locating Length Error:	±0.2mm
Cutting Angle Error:	4'
Surface Plainness:	0.1mm
Overall Dimension:	550017501990mm

Parker Machinery Co., Ltd., China has developed the assembly line equipment for door-window, curtain walls and Insulating glasses process. The operation of high precision, advancement and specialty makes the enterprise well-known. She sets an example for her pure quality and excellent service. So she becomes the reliable cooperative partner of the door-window enterprise for her responsibility.

Parker machines sell well, become well-known and outstanding at the national fairs of door-window equipment, owing to:

Using of European standards, and taking in the view and pithy of the design.

Purchasing main parts internationally.

Selling machines to other countries, such as USA, India, UAE, Brazil, Iran, North America, South Africa, Russia, Korea, Middle East, and so on.

Carrying our "Handover key project" ahead of other in this area.

Combining the manufacture with the development of design software of door-window.

Owing more than twenty sales and service agencies.

To meet the great need of development of hi-grade door-window, combining with almost ten years of experience, we introduced advanced technology from other countries, and developed five types, more than forty specifications of door-window and curtain wall equipment. Door-window factories needn't import any hi-grade machine from other countries any more.

Let's share science and technology of the world!

Parker machine core parts procurement achieved internationalization, and established a cooperative partnership with ABB, Omron, Schneider, Optima. PARKER people are always follow the core concept, it is "Parker is developing with the world", it is PARKER peoples' strict implementation of ecological system of Parker and of "zero defect" stern pursuit, which makes the Parker machine perfect implement unique global standard, achieves improvement value and sustainable innovation!

Parker machinery exports to the world more than80 countries and regions, and has firstly established branches in USA, India, UAE, Brazil, has 50 patents. PARKER products include aluminum, PVC windows and doors machinery, aluminum curtain wall processing machinery, industrial aluminum processing machinery and insulating glass series production line machinery. Parker machinery are all passed through high standard European CE certification, American UL certification and Canadian CSA certification.
