12m Battery Power Self-Propelled Scissor Lift Platform for Warehouse

12m Battery Power Self-Propelled Scissor Lift Platform for Warehouse
Price: US $ 2999-14800/Piece
Min Order: 1/Piece
Pay Type: L/C,T/T
Prod Model: SJY0.3-12
Item: Self-Propelled Scissor Lift Platform
Power: 3.0kw
Max. Lifting Height: 11800mm
Min. Lifting Height: 1800mm
Table Size: 2300 X 1150mm
Load: 300kgs
Self Weight: 2580kgs
Warranty: 2 Years
Overall Dimensions: 2500 X 1150 X 2080mm
Material: High Duty Mn Steel
Application: Building Crane
Carrying Capacity: Light Level
Driven Type: Hydraulic
Running Mode: Moving
Feature: Explosion-Proof

Product Description

12m battery power self-propelled scissor lift platform for warehouse

Application:
1) Self moving, without outriggers.
2) One person can control  self-propelled scissor lift platform on work platform when raised.
3) The  self-propelled scissor lift platform applies to indoors, field or uneven conditions.
It's widely used for aerial installation and maintenance without power supply, with smooth working grounds, such as hotels, grand hall, sport stadium, large factory, workshops, warehouse, granary, bus and railway stations, hotels, and airports.



Main parameters for  self-propelled scissor lift platform:

Model No.

SJG0.3-12

Dimensions:

Max. Platform Height

11.8m

Max. Working Height

13.8m

Height ( stowed )

2.535m

Height ( guardrail fold stowed )

2.085

Min. Platform height

1.435m

Platform Size

2.3 m * 1.15m

Platform Extend Length

0.8m

Ground Clearance

0.1m

Productivity:

Load Capacity

300kg

Load capacity on extension deck

100kg

Drive Speed(Platform Stowed)

0 - 3.2km/h

Drive Speed(Platform Elevated)

0 - 0.8km/h

Turning Radius

2.35m

Grade-ability

25%

Drives

Dual front wheel

Brakes

Dual rear wheel

Tire size

0.305 * 0.125m

Power:



Batteries

24V DC (4 x 6V 225Ah batteries)

Motor power

3KW

Standards Compliance

 CE / ISO

Overall Net Weight

2580kgs

Our services:
1) We can design the  self-propelled scissor lift platform as per your requirement.
2) The most suitable  self-propelled scissor lift platform will be recommended to you once we get your requirement.
3) Shipment can be arranged from our port to your destination port.
4) Operation video can be sent to you if needed.
5) User-friendly English manual for machine installation using and maintenance.
6) 2 years warranty for whole machine without man-made faults
7) We will send you parts for free if there are any non-human factors faults during warranty time.
8) Supply 24-hours technical assistance by email, telephone or other communication online.
9) We could reply you in 2 hours after received your any questions even on weekend and holiday.
    Engineers are available to your country if necessary.


Contact me:
 Tel:86-531-85882730
Phone: +86-17865151171              Fax:86-531-62321282

Shandong Lift Machinery Co., Ltd is one of the leading manufacturer of heavy duty scissor lifts and car parking lifts in China. Being in this field for over 59 years, and exported lift machine more than 17 years till 2017. Our main products are stationary scissor lift, mobile scissor work platform, car park lift, cargo elevator, disable wheelchair lift, aerial aluminum lift ladder, and mobile container loading ramps etc.

Now there are more than 116 staffs in our factory, and 10 production lines in 8 workshops. There is a engineer team focus on research, development and innovation. The biggest load weight of our scissor lift is 100tons. All the products are passed the test held by Check Station of China Special Equipment and Manufacture.

We regard ''reasonable prices, efficient production time and good after-sales service'' as our tenet, and hope to cooperate with more customers for mutual development and benefits. We sincerely welcome each potential customer to visit our factory!
