| Prod Model: |
DM4-HS026 |
| Surface Coated: |
Coffee |
| Hardness: |
58-63 HRC |
| Flute Type: |
Spiral Flute |
| Model Of Making: |
Full Ground |
| Usage: |
Drilling Metal |
Product Description
This left-hand drill bit set has a 135 degree split point for fast penetration. The bits are made of high speed steel with a titanium coating to fight corrosion. Use these bits with a reversible drill (available separately) to remove studs, screws and bolts without damaging threads in the hole. The left-hand drill bit set comes in a steel storage case for portability.
1.Material:HSS4341,6542,9341,M35,M42
2.Point Angle: 118 degree or 135 degree Split Point
3.Shank Type: Cylinder
4.Surface finshing:black, white,black&white,Amber,Tin coated
5.Processing: Fully ground
6.Diameter: 1/16 in., 5/64 in., 3/32 in., 7/64 in., 1/8 in., 9/64 in., 5/32 in., 11/64 in., 3/16 in., 13/64 in., 7/32 in., 15/64 in., 1/4 in.
135 degree split point for fast penetration
High speed steel
Double flute
Steel storage case
Model of Making: Full Ground Or Roll Forged
Material: High Speed Steel or S2
H.S.S Grade |
Chemical Composition(%) |
4241 |
W:1.50-2.50; Mo:0.60-1.20; Cr:3.80-4.40; V:0.50-0.70 |
4341 |
W:3.50-4.50; Mo:2.50-3.50; Cr:.3.80-4.40; V:1.20-1.80 |
99341 |
W:8.50-9.50; Mo:2.70-3.30; Cr:.3.80-4.40; V:1.30-1.70 |
6542(M2) |
W:5.50-6.75; Mo:4.50-5.50; Cr:.3.80-4.40; V:1.75-2.20 |
M35 |
W:6.00-6.70; Mo:4.70-5.20; Cr:.3.80-4.50; V:1.70-2.00; Co:4.50-5.50 |
M42 |
W:1.15-1.85; Mo:9.00-10.0; Cr:.3.50-4.25; V:0.95-1.35; Co:7.75-8.75 |
