| Prod Model: |
DS-22 |
| Markets: |
South America,Eastern Europe,Southeast Asia,Africa,Mid East,Eastern Asia |
| Application: |
Multi Granite Cutting/ Block Cutting |
| Segment Type: |
Sandwich,Grooved,etc. |
| Name: |
1600mm Conical Multi Diamond Segment |
| Material: |
Diamond Crystal, Metal Powder |
| Dimension: |
Normal or Special |
| Blade Diameter: |
1600mm |
| Dimension1: |
23X8/7X13 |
| Dimension2: |
24X9.2/8.4X13(15) |
| Craft: |
Sintering,Braded,Welding |
| Quality: |
100% Check |
Product Description
1600mm Conical Multi Diamond Segment for Egypt Granite Block
Features and dimension:
1.Conical design multi segment work in low nosie,small cutting slot which ensure max use of stone and uniform thickness.
2.Stable cutting,narrow cutting gap,stone waste reduction.
Product Name | Specification | Core Thickness | Segment Dimension | Segment Number |
| JDK Multi Blocking Cutting Segment | Φ1000 | 5.5/5.0 | 24x7.0/6.2x13(15) | 70 |
| Φ1200 | 6/5.5 | 24x7.5/6.5x13(15) | 80 |
| Φ1400 | 6.5 | 24x8.4/7.6x13(15) | 92 |
| Φ1600 | 7/7.2 | 24x9.2/8.4x13(15) | 108 |
About JDK
JDK has been engaged in manufacturing and exporting worldwide quality diamond tools since 1995.Main products are Diamond Blades,Diamond Segments,Diamond Wire Saw,Diamond Fickert/Frankfurt,Diamond Router Bit,Diamond Cup Wheels,Diamond Polishing Pads as well as PCD/HTC Tools.
Ways of Transportation/Delivery
1) As for urgent order or sample order with light weight, JDK recommends Express Service.
2) As for normal (regular) order weighting over 45kgs, JDK recommends Air Cargo.
3) As for big diameter saw blade or order with heavy weight, JDK recommends Sea Cargo.
4) We will inform you the approximate shipping date before order placing.
Welcome to contact us!
Quanzhou JDK Diamond Tools Co., Ltd. is one professional manufacturer of diamond tools in China, specially for the stone working industry. The main products are stone cutting Diamond Saw Blades, Kinds of Diamond Segments, Diamond Abrasives, etc...For over 12 years development with the support of JDK's Customers, suppliers and Staffs, now JDK is supplying big range stone cutting, Grinding & Polishing tools to the world.
JDK was established in 1995, initially JDK was producing and selling diamond tools products to China domestic market. Since 2000 year JDK is aiming at the world market and started to design and produce superior performance diamond tools to meet kinds of requirements of customers from all over the world. with these years export experiences now JDK is exporting his diamond tools products to over 30 countries which is in Europe, Middle East, Asia, America, etc...
JDK's experienced Engineer and R&D team are providing customers quality stone tools for cutting, grinding, polishing, milling, drilling, such as diamond saw blade, diamond segments, Diamond Wire Saw, Diamond abrasives, Flexible Polishing Pads, Grinding Cup Wheels, Core Drill Bits, ...
Always, JDK's target: Offer you most satisfied products and service, developing together.
