| Prod Model: |
SAE 100 / DIN EN 853 / RUSSIA GOST |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| 1sn 2sn 4sp 4sh: |
1/4"~3" |
| Material: |
Nitrile Rubber |
| Color: |
Black |
| Capability: |
Rubber Oil Hose |
Product Description
Hyrubbers Co., Ltd is manufacturer of various hydraulic hose in north of China , We have been in this line for over 10 years and have many customers and distributors in USA , Italy , Russia , Ukraine , Brazil ,Chine ,Argentina ,Peru , Iran , UAE , Egypt ......
Our Main Products:1 HYDRAULIC HOSE
SAE R1AT/DIN 1SN
SAE R2AT/DIN 2SN 1ST/1SC 2ST/2SC
4SH/4SP
R13/R15/R16/R17/R14
R3/R6/R7/R8
Drilling Hose (38mm~150mm)
2 INDUSTRIAL HOSEWater / Air Hose smooth surface , warpped surface
Fuel Hose
Gas Hose
Oxygen Hose
3 ACCESSORIES (valves, quick couplings, clamps)
Service:1. )Excellent quality with most effective price
2. )Fast delivery time and good service after sale.
3. )Free samples to test quality.
4. )You can find us on the two session of the Canton fair every year.
| DN | Hose I.D | Wire O.D | Hose O.D | Working Pressure | Burst Pressure | Minimum Bend Radius | Weight | Length |
| inch | mm | mm | mm | MPa | psi | MPa | psi | mm | kg/m | metres |
| 5 | 3/16 | 4.8 | 9.5 | 11.8 | 25.0 | 3630 | 100.0 | 14280 | 89 | 0.19 | 50/100 |
| 6 | 1/4 | 6.4 | 11.1 | 13.4 | 22.5 | 3270 | 90.0 | 12840 | 102 | 0.21 | 50/100 |
| 8 | 5/16 | 7.9 | 12.7 | 15.0 | 21.5 | 3120 | 85.0 | 12280 | 114 | 0.24 | 50/100 |
| 10 | 3/8 | 9.5 | 15.1 | 17.4 | 18.0 | 2615 | 72.0 | 10280 | 127 | 0.33 | 50/100 |
| 13 | 1/2 | 12.7 | 18.3 | 20.6 | 16.0 | 2320 | 64.0 | 9180 | 178 | 0.41 | 50/100 |
| 16 | 5/8 | 15.9 | 21.4 | 23.7 | 13.0 | 1890 | 52.0 | 7420 | 203 | 0.45 | 50/100 |
| 19 | 3/4 | 19.0 | 25.4 | 27.7 | 10.5 | 1530 | 42.0 | 6000 | 241 | 0.58 | 50/100 |
| 25 | 1 | 25.4 | 33.3 | 35.6 | 8.8 | 1280 | 35.0 | 5020 | 305 | 0.88 | 50 |
| 32 | 1 1/4 | 31.8 | 40.5 | 43.5 | 6.3 | 920 | 25.0 | 3600 | 419 | 1.23 | 20/40 |
| 38 | 1 1/2 | 38.1 | 46.8 | 50.6 | 5.0 | 730 | 20.0 | 2860 | 508 | 1.51 | 20/40 |
| 51 | 2 | 50.8 | 60.2 | 64.0 | 4.0 | 580 | 16.0 | 2280 | 635 | 1.97 | 20/40 |
We are the professional Manufacturer of hydraulic hose and industrial hose in China. All our products are tested strictly and pass the ISO9001: 2000 and SGS quality system certifications.
Our below products have been exported America, Europe, the Middle East, South Africa, more than 20 countries and regions.
Hydraulic Hose---
SAE R1AT/DIN 1SN SAE R2AT/DIN 2SN
1ST/1SC 2ST/2SC 4SH/4SP
R13/R15/R16/R17 R3/R6/R7/R8
High Pressure Wash Hose
EPDM /Metal /Teflon Hose...
Industrial Hose---
Oil Hose
Steam Hose
Welding hose
Air /Water Hose
Suction and Discharge Hose
