3 Wing Drill Bit & Hf Drill Bit
| Price: |
US $ 1800-2200/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: |
drill bit |
| Type: |
PCB Drilling |
Product Description
3 wing drill bit & HF drill bit
1,Application:
1,Suit for drilling medium to medium-hard formations.
2,Evolute asymmetrical blade cutter design and balanced bit load so that bit whirl is prevented .
3,Composite gage protection and low torque design improve rate of penetration .
4,CFD hydraulic balance design results in better bit cleaning and cutting removal .
5,Combined utilization of high performance PDC compacts significantly prolongs bit life
Higher nozzle counts and/or fixed ports to best serve cleaning,cooling and cuttings evacuation requirements with available hydraulic flows.Allows for higher flow rates with minimal increase in pump pressure.
Feature:Diamonds are impregnated in the matrix behind the PDC cutters
Benefit:Increased footage drilled in abrasive applications
2.details:
Bit type | Main bit size(mm) | Rock coefficient |
PDC core drill bit | Single pipe | 75/54.5 94/74 113/89 113/109 153/129 | 1-18 |
Two-pipes | 75/54.5 94/68 |
PDC center drill bit | Concave 3 wing bit | 60 75 94 113 133 | 1-18 |
Arc pillar | 60 75 94 113 133 | 4-18 |
Many wing scraper | 60 75 94 113 133 133 153 173 190 215 | 1-6 |
PDC Indexable drill bit | 153/94 153/113 190/153 190/113 | 1-18 |
Model | 118,152,215.9,244,311,445 |
Type | all kinds and size PDC bits |
Applicable | water well, oil field, construction, geothermal, directional boring, and underground foundation work |
Formation | sticky, soft, medium hard, hard formation |
blade | 4,5,6,7,8,9 |
Packing | wooden box |
Payment Term | T/T |
MOQ | 1 Piece |
Supply Ability | 1000 Pieces/month |
Delivery Time | within 7-15 work days |
