| Prod Model: |
SY-JP-01 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Painting Color: |
as Customer's Request |
| Support: |
OEM & ODM |
| Logo Carving: |
Laser Printing |
| Grade: |
a-Grade |
| Formula: |
Special Formula for Your Stone's Properties |
| Characteristic: |
Long Life |
| Certification: |
BV/SGS/ISO |
| Advantage: |
Quality and Price |
| Diamond Quality: |
Premium Diamond |
| Supplier: |
Quanzhou Sunny Superhard Tools Co., Ltd. |
| Shape: |
Round |
| Manufacturing Arts: |
Welding |
| Usage: |
Stone Cutting |
| Customized: |
Non-Customized |
| Graininess: |
Success Formula for Stone Concrete Cutting |
| Thickness: |
Depend on Diameter |
| Kind: |
Diamond Circular Saw Blade |
| Brand: |
Sunny |
| Saw Blade External Diameter: |
300mm---3500mm |
| Specification: |
300mm---3500mm |
Product Description
DESCRIPTION
Diamond Saw Blades for Slab Edge Cutting of Marble, Limestone, Slate, Kinds of Soft Stones without quartz, Suitable for Bridge Cutting Machine, Manual Handling Cutting Machine & Table Cutting Machine.
Our Diamond Saw Blades are highest Ratio of Performance to Price! Made In China.
Marble Slab Cutting Saw Blades have a bond designed to optimize your saw's cutting performance when cutting marble or other soft stone, such as travertine and limestone.
Marble cutting blades provide efficient cutting in soft materials, as well as providing a smooth cut. The fact that a marble blade leaves a better working area is key to finishing the job in less steps. Sunny Marble Blades allow you to do this by providing a chip free edge and consistent cut of marble and soft stone.
Remember the surface feet per minute should be faster when cutting marble. Adjust your saw's RPM or you can compensate by using a larger size marble blade than granite. Example: If RPM is set for using 14" granite blade, leave saw at that RPM, but use a 16" marble blade.
FEATURE
1. The blade has good sharpness and high efficiency at the process of cutting.
Long lifespan
2. Good cutting result: Smooth cutting, flat surface and even size.
3. Stable cutting, narrow cutting gap, stone waste reduction.
Different formula for different hardness and abrasive of the material.
SPECIFICATION
Diameter
(mm/Inch)Hole
(mm)Segment Height
(mm)Segment No.
(PCS/set)Steel Blank TypeWelding Method
250mm(10")50/607/8/1018Normal
&
SilentSilver Welded
300mm(12")50/607/8/1021
350mm(14")50/607/8/1024/25
400mm(16")50/608/1028
450mm(18")50/608/1032
500mm(20")50/608/1036
550mm(22")50/608/1038
600mm(24")50/608/1042
625mm(25")50/608/1044
700mm(28")50/608/10/1250
725mm(28")50/608/10/1250
750mm(30")50/608/10/1252
800mm(32")50/608/10/1246
Other specifications are also available.
Diameter
(mm) | Segment Dimension (L × W × H) | Steel Core Thickness | Segment No. | Segment Structure |
| Length | W (Taper Type) | Height |
| 900 | 24 | 7.0/6.5 | 10/12/15/20 | 5.0mm | 64 | Multi-Layers
or
Sandwich |
| 1000 | 24 | 7.0/6.5 | 10/12/15/20 | 5.0mm | 70 |
| 1100 | 24 | 7.4/6.8 | 12/15/20 | 5.5mm | 74 |
| 1200 | 24 | 7.5/7.0 | 12/15/20 | 5.5mm | 80 |
| 1300 | 24 | 8.0/7.5 | 12/15/20 | 6.0mm | 88 |
| 1350 | 24 | 8.4/7.7 | 12/15/20 | 6.0mm | 88 |
| 1400 | 24 | 8.5/8.0 | 12/15/20 | 6.5mm | 96 |
| 1600 | 24 | 9.0/8.7/8.4 | 12/15/20 | 6.5mm | 104/108 |
| 1700 | 24 | 9.4/8.9/8.4 | 12/15/20 | 7.0mm | 112 |
| 1800 | 24 | 9.5/9.0 | 12/15/20 | 7.0mm | 120 |
| 2000 | 24 | 10.5/10/9.5 | 15/20 | 8.0mm | 128 |
| 2200 | 24 | 11.5/11/10.5 | 15/20 | 8.5mm | 132/136 |
| 2500 | 24/30 | 12/11.5/11 | 15/20/25/30 | 9.5mm | 140 |
| 2700 | 24/30 | 12/11.5/11 | 15/20/25/30 | 9.5mm | 140 |
| 3000 | 24/30 | 12.5/12/11.5 | 15/20/25/30 | 10.0mm | 160 |
| 3500 | 24/30 | 13/12.5/12 | 15/20/25/30 | 10.0mm | 180 |
QUANZHOU SUNNY SUPERHARD TOOLS Co., Ltd is a professional and Dynamic Diamond Tools manufacturer, established in 1993, Located in Quanzhou, Fujian province, China, factory covering 15000 square meters. Our technical department is composed of experienced professors and engineers. We devote ourselves to researching and manufacturing cutting and processing Diamond tools for nature stone and building materials. Our tools are exported to more than 60 countries, including America, Brazil, Italy, Russia, Ukraine, India, Egypt, South Africa etc.
Main Products:
Cutting Tools (Saw blade, Segment, Wire saw etc)
Grinding&Polishing Tools (Calibration Rollers, Fickerts, Frankfurt, Cup wheel, Profilling wheel, Polishing pad, brush etc)
Drilling Tools (Finger Bit, Core drill etc)
The Philosophy of Sunny is "Superior product and service derived from standard and efficWe have a high efficiency team, each department strictly comply with company regulations.
From receiving your enquiry, put order in production and Dispatch to after-sales service, Ient management. "
In order to provide customer most suitable tools, we keep researching and analysing nature stone and engineering material. We cooperate with stone factory to test tools, and keep close contact with our customers by visit or communication to get knowledge of market demand.
We Response All Your Request efficiently To Save Your Time And Provide Your Utmost Convenience.
The deep understanding for customer's demand and strict quality control help us developing quickly, we wish to get your collaboration to achieve our objectives together!
Our aim is to provide our clients stable and consistant quality with competitive price.
Advantages enable clients benefits from our tools.
1. Experienced bond system
2. Advanced equipment and high grade raw material
3. Strictly production procedures control and quality inspection.
4. Customer's active feedback and support help us developing fast.
