| Prod Model: |
JDK-C047 |
| Diameter: |
350mm |
| Segment Dimension: |
40*3.2*15(20)mm |
| Segment No.: |
24 |
| Core Thickness: |
2.4/2.2mm |
| Arbor: |
50/60mm |
| Work Condition: |
Wet |
| Type: |
Silent or Non-Silent |
| Blade Material: |
Alloy Steel |
| Delivery Time: |
3 Days After Payment |
| Supply Type: |
Mannufacuter |
Product Description
Features:
Diamond saw blades for edge cutting of slabs of marble, limestone , kinds of soft stones without quartz, suitable for Bridge cutting machine and manual handling machine.
1.Good continuity , effectively reduce the distandce between teech , cutting edge doesn't collapse.
2.The blade has good sharpness and high efficiency at process of cutting.
Specification:
| Diameter | Inch | Core Thickness | Arbor | Segment Size | Segment Number |
| mm | inch | mm | mm | mm | pcs |
| φ250 | 10" | 2 | 25.4/50/60/ 80/100/120/ 150 | 40*2.8/3.0*8(10)(12)(15) | 17 |
| φ300 | 12" | 2.2/2.0 | 40*2.8/3.0*8(10)(12)(15) | 21 |
| φ350 | 14" | 2.2/2.4 | 40*3.0/3.2*8(10)(12)(15)(20) | 24 |
| φ400 | 16" | 2.6/2.8 | 40*3.4/3.6/3.8*8(10)(12)(15)(20) | 28 |
| φ450 | 18" | 2.8/3.0 | 40*4.0/4.2*8(10)(12)(15)(20) | 32 |
| φ500 | 20" | 2.8/3.0 | 40*4.0/4.2*8(10)(12)(15)(20) | 36 |
| φ600 | 24" | 3.6 | 40*4.6*8(10)(12)(15)(20) | 42 |
| φ700 | 28" | 4.0 | 40*5.2*8(10)(12)(15)(20) | 42 |
| φ800 | 32" | 4.5 | 40*6.0*8(10)(12)(15)(20) | 46/57 |
| φ900 | 36" | 5.0/5.5 | 24*6.6/6.0*8(10)(12)(15)(20) | 64 |
| φ1000 | 40" | 5.0/5.5 | 23*7.0/6.2*8(10)(12)(15)(20) | 70 |
| φ1200 | 48" | 6.0 | 23*7.5/6.9*8(10)(12)(15)(20) | 80 |
| φ1350 | 54" | 6.5 | 23*8.0/7.2*8(10)(12)(15)(20) | 88 |
| φ1600 | 64" | 7.2 | 23*9.2/8.4*8(10)(12)(15)(20) | 108 |
| φ1800 | 72" | 8.0 | 24*10/9.2*8(10)(12)(15)(20) | 120 |
| φ2000 | 80" | 8.0 | 24*10.4/9.6*8(10)(12)(15)(20) | 128 |
| φ2200 | 88" | 9.0 | 24*11/10.2*15(20) | 132 |
| φ2500 | 110" | 9.0 | 24*11.5/10.5*15(20) | 140 |
| φ3000 | 120" | 10.0 | 24*12.5/11.5*15(20) | 160 |
| φ3500 | 140" | 10.0 | 24*14.5/13.5*15 (20) | 180 |
Packing & Shipping:
Packing:
The inner packaging is carton box .The outer packaging is carton box Or woodencase.
(If by air ,carton box will reduce the weight, if by sea, we suggest woodenbox for waterproof.)
Shipping:
1. Trail order with light weight(<45kgs), we recommend Express Service.
2. Normal order weighting over 45kgs, we recommend Air Cargo.
3.As for the large size or heavy weight, JDK recommends Sea Cargo.
Our Advantages:
Factory = Our Own Exporting License
Manufacturer = Competitive Price
Own Technology = OEM
Our Service:
1.Profesion:Provided all diamond tools for stone processing.
2.Customized Design:We can produce according to your request.
3.OMD/OME service
4. Logo printing
5. MOQ:Any quantity you need is welcomed.
Welcome to contact us!
Quanzhou JDK Diamond Tools Co., Ltd. is one professional manufacturer of diamond tools in China, specially for the stone working industry. The main products are stone cutting Diamond Saw Blades, Kinds of Diamond Segments, Diamond Abrasives, etc...For over 12 years development with the support of JDK's Customers, suppliers and Staffs, now JDK is supplying big range stone cutting, Grinding & Polishing tools to the world.
JDK was established in 1995, initially JDK was producing and selling diamond tools products to China domestic market. Since 2000 year JDK is aiming at the world market and started to design and produce superior performance diamond tools to meet kinds of requirements of customers from all over the world. with these years export experiences now JDK is exporting his diamond tools products to over 30 countries which is in Europe, Middle East, Asia, America, etc...
JDK's experienced Engineer and R&D team are providing customers quality stone tools for cutting, grinding, polishing, milling, drilling, such as diamond saw blade, diamond segments, Diamond Wire Saw, Diamond abrasives, Flexible Polishing Pads, Grinding Cup Wheels, Core Drill Bits, ...
Always, JDK's target: Offer you most satisfied products and service, developing together.
