| Prod Model: |
DM4-H043 |
| Size: |
0.5-20mm |
| Hardness: |
HRC61-66 |
| Sharpening: |
118&135 Degree Point |
| Process: |
Fully Ground |
| Surface Finish: |
Black,White,Rainbow,Coffee Color |
| Flute: |
N or Va |
| Usage: |
Metal Drilling |
| Shank: |
Straight Shank Drills |
Product Description
Product Information
Drill bits are cutting tools used to create cylindrical holes, almost always of circular cross-section. Bits are held in a tool called a drill, which rotates them and provides torque and axial force to create the hole. Specialized bits are also available for non-cylindrical-shaped holes.
HSS drill Standard: : DIN 338 (jobber series),DIN 340 (long series),DIN 1897 (stub series)
Manufacturing Process: Fully Ground, Milled, Rolled, Edge Ground.
Material: HSS4241, HSS4341, HSS6542(M2), HSS Cobalt 5% (M35 Co5%)
Surface: Black finish, Bright finish, Black & Bright finish, Tin-coated Finish, Amber / Coffee Finish, Rainbow Color Finish.
Packing: PVC Pouch, Paper Box, Plastic Box, Plastic tube, Metal Box or as per the customer's requirement.
Size: 1mm-30.0mm
Point Angle: 118° or 135° (Split Point are available from 3.0mm)
Application: For drilling steel, cast steel, grey cast iron, malleable iron, sintered metal, low hardness alloyed
Detailed Specification
| HSS Drill Bits | | | | | | | | | | | |
| Manufacturing | Surface Finish | | | | | | Sharpening | | | | |
| | White | Black | B&W | Tin Coated | Amber | Black&Gold | 118° | 135°S.P. | Turto Max | 118°S.P | Web Thinning |
| Rolled Forged | | √ | √ | | | | √ | √ | | √ | |
| | | | | | | | | | | | |
| Rolled Polished | √ | √ | √ | √ | √ | | √ | √ | | √ | |
| | | | | | | | | | | | |
| Fully Ground | √ | √ | √ | √ | √ | √ | √ | √ | √ | √ | |
| | | | | | | | | | | | |
| Milled | √ | √ | √ | √ | | √ | √ | | | | √ |
| | | | | | | | | | | | |
| Standards | DIN338,DIN1897,DIN340,DIN1869,DIN345,DIN333 | | | | | |
| | Jobber length,ScrewMachine Length,Taper length,Aircraft Extension | | | |
| Material | HSS4241,HSS4341,HSS6542(M2),HSS CO5%(M35),HSS CO8%(M42) | | | |
| Shank | Straight shank(Parallel shank), Reduced Shank, hex shank,1/4″Quick change shank,3Flats shank,1/2"shank | | | |
| Helix Angle | Type N,Type W,Type H | | | |
| Rotating | Right Hand,Left Hand | | | |
| Flute | Normal,parabolic | | | |
| HSS GRADE | HRC(Rockwell Hardness) |
| Mo2Cr4Vsi--4241 | 60-62 |
| Mo3Cr4Vsi--4341 | 62-65 |
| Mo3Cr4V---9341 | 63-66 |
| Mo5Cr4V2-6542/M2 | 63-66 |
| Mo5Cr4V2Co5-M35 | 64-67 HSS Co5% |
Packing Information
A. Plastic pipe packing
B. Metal displaybox packing
C. Plastic tube packing
D. Plastic displaybox packing
E. 1pc / PVC bag,then 1pc / inner paper box
F. Grey metal displaybox packing
G. Metal box for drill bits set packing
H. Wooden box for drill set packing
J.5/10 pieces packind in PVC bag, then in white paper box, then in carton
Shipping
1. TNT/FedEx/DHL/UPS for samples or under 45KG weight goods , Door to Door.
2. By Air or by Sea for batch goods,from airport(seaport) to airport(seaport).
3. Customers specifying freight forwarders or not.
4. Production Time: 3- 7days for samples; 2-3.5 weeks for batch goods
Our company
1) We're a direct manufacturer and 100% export to worldwide(USA, Isrel, Jordan, Iran, Thailand,Duabai, South Africa, Kenya, Egypt, Australia, UK, Spain, Brazil, etc)
2) We have around 15 years producing experience.
3) Our drill product:HSS drill bits, masonry drill, SDS drill,glass&tile drill, step drill, wood flat drill, wood auger bit, wood brad drill, center drill, left hand drill, drill set etc.
4) Above 95% customers will place a formal order after testing the samples.
