| Price: | US $ 2200/Piece |
|---|---|
| Min Order: | 1/Piece |
| Pay Type: | L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: | 6040 |
|---|---|
| Laser Type: | CO2 Sealed Glass Laser Tube |
| Service: | Engineers Available |
| Engraving Area: | 600X400mm |
| Table: | Honeycomb or Knife Shaped |
| Motor: | Stepper |
| Laser Power: | 60W/80W/100W Reci/Efr Optional |
| Rotary Axis: | Yes or Optional |
| Cooling Model: | Water Cooling |
| Laser Material: | Acrylic, Glass, Leather, MDF, Paper |
| Working Area: | 600mmx400mm |
Features of co2 laser engraving machine
1.New design, High quality with competitive price.
2.Red light positioning, help find the work point, protect workers and improve work efficiency.
3. Advanced LCD Touch Screen+ USB port+ DSP Offline Control, which can not only work without computer, but also connect to U disk, USB communication.
4. Imported high precision linear guide rail and professional optical system, dustproof and lubricate, which improve the engraving quality and prolong machine lifetime.
5. Special Front and back running-through design, the unique door for the limitless engraved materials through.
6. Professional Honeycomb or Strip work table, which meet the needs of diversified laser procession;
7. Water Cooling System with Alarm Protection, adopt CW-3000 Water Chiller with temperature display,
which can avoid over burning, to protect the water circulation from electricity-off.
8. Equipped with luxury Consumables, Imported Focus Lens and reflect mirror, Chinese Best Quality Laser Tube,
Reci Laser Tube and RF metal tube for your choose, makes high efficiency and steady.
9. High speed stepper subdivision driver control, numeral timing, simulation quantum control laser power, little error, repetition high precision,
engrave 1×1mm little English character perfect.
10. Optional Motorized up-down work table with Auto Focus Function, very good for precise focusing and different cutting depth requirement for lots of material;
11. Optional 3D Rotary System, engrave circumrotately 360 degree, applicable in column or cone work piece surface.
600x400mm Laser Cutting And Engraving Machine With Rotary Axis| Laser type | Hermetic and detached CO2 |
| Working area | 600*400mm |
| Laser power | 80w(100/130/150w for option) |
| Control system | Ruida or Leetro |
| Driver and motor | Leadshine driver and motor |
| Transmission | Hiwin square rail and high quality belt |
| Lens and mirror | Imported from Singapore |
| Work table | Honey comb or blade |
| Red dot position | With |
| Machine color | White and blue or black and red |
| Delivery time | 10 days |
| Payment | T/T; L/C; Western Union |
| Cooling mode | Circulating-water-cooling |
| Power adjusting | 0-100%controlling,adjusting by software |
| Max engraving speed | 60m/min |
| Max cutting speed | 50m/min |
| Repeating location | ±0.01mm |
| Minimum Character | Chinese character 1.5mm, christcross-row 1mm |
| Working voltage | AC220V 50/60HZ |
| Body dimension(L*W*H) | 1500*1260*1000mm |
| Packing | Export wooden case |
| Gross weight | 200KG |
| Working environment | Temperature: 0-45,Humidity: 5%-95% |
| Controlling software language | Chinese, English, French, Russian, Portuguese, Turkish, German |
| Dictate format | *.plt,*.dst,*.dxf,*.bmp,*.dwg,*.al,*las, Support AutoCAD, CoreDraw direct outputting |
| Optional Equipment | |
| Optional | Rotary axis |
| Up down table | |
| Water chiller | |
| CCD camera | |
Application of co2 laser engraving machine
Applicable Materials: wood, acrylic, organic glass, crystal, fabric, paper, leather, rubber, ceramic, and other non-metal materious,plastic,
cloth toys,leather ,computer embroidery cutting ,mould ,crafts ,bamboo and wood ,advertising and building decoration ,packaging and printing ,paper products.
Typical Application: Acrylic crystal words,acrylic fish tank,ceramic crafts,rubber board printing,applique,special-shaped trademark,
engraving and hollowing out patterns or designs on garment and leather
1. 24 hour Technical support by phone, e-mail or MSN around the clock.
2. Friendly English version manual and operation video CD disk.
3.7-15 working days after down payment or full payment.
4. Machine will be adjusted before it is delivered; operation disk/CD was included.
5. Our technician can give you remote guide online (Skype or MSN) if you have any question.
6. Engineers available to service machinery overseas, seller and buyer discuss the charges.
Q1: How can I get the best machine for me?
You can tell us your working material, detail work by picture or vedio so that we can judge whether our machine can meet your need or not. Then we can give you the best model depends on our years of experience.
Q2: This is the first time I use this kind of machine, is it easy to operate?
We will send you manual and guide vedio in English, it can teach you how to operate the machine. If you still can not learn how to use it, we can talk by phone, video call ,email or other contact ways.
Q3: If the machine has problem in my place, how could I do?
We could send free parts to you in warranty period if machines have any problem under "normal use", and we provide engineers available to service machinery overseas.
Q4: This model is not suitable for me, do you have more models available?
Yes, we can supply many models. such as advertising cnc router, metal cnc router, wood cnc router, stone cnc router and so on.
Replacement of some part based on your need. The above are most popular. If it can not meet your requirement, then tell us. We have the ability to make specially according your requirement!
Q5:What's the guarantee, in case the machine breaks down?
The machine has 2 years guarantee. If it breaks down, generally speaking, our technician will figure out what the problem may be, according to client s feedback. Parts except for consumable parts will be replaced for free if the problems are caused by quality fault.
Q6:How about the documents after shipment?
After shipment, we ll send all original documents to you by DHL, including Packing List, Commercial Invoice, B/L, and other certificates as required by clients.
Q7:How long is the delivery time?
For standard machines, it would be 7-10 days; For non-standard machines and customized machines according to client s specific requirements, it would be 15 to 30 days.
Q8:How's the payment?
We provide L/C,D/A,D/P,T/T,Western Union,MoneyGram,Paypal payments for offline orders and online orders
Q9:Do You Arrange Shipment For The Machines?
Yes, dear esteemed customers, for FOB or CIF price, we will arrange shipment for you. For EXW price, clients need to arrange shipment by themselves or their agents.
Q10:How is the packing?
Water-proof plastic film package with foam protection in each corner
Solid Seaworthy Wood Box Package with Steel Belt
Save space as much as possible for container loading
