Model Number: |
Steel Tooth Bit, TCI Bit |
Bearing Type: |
Sealed Bearing and Non-Sealed Bearing |
Suitable Formation: |
Soft, Medium Soft, Hard, Medium Hard, Very Hard |
Color: |
Blue or Red |
IADC Code: |
114~837 |
Type: |
Drill Bit |
Material: |
Alloy Steel, Tungsten Carbide |
Product Description
8 1/2" oil drilling tricone button bits drilling rig diamond cutting tools price
The roller- cone bits are used to drill all kinds of formations, from soft to hard. The softer formations use steel-tooth bits, and the harder use tungsten carbide.
The biggest advantage the tricone bits have over any other drill bit is the test of time. They have been proven time and time again, and they're the best at controlling the trickier situations. Tricones' ability to handle both soft and hard formations gives them the flexibility that other drill bits do not have.
Packaging
Wood Box
Fumigation Tray if necessary
Other special package can be applied
according to customer's need
Delivery
Lead Time:
Prepared to deliver within 1 week, if in stock
Depends on order quantity, when out of stock
Transportation:By sea or air
Hejian Hengji Bit Manufacture Co.,LTD was established in 1990. we have kept our clients ahead of schedule and under budget by providing the highest quality tools at the best possible prices .
We ship to more than 60 different countries and serve industries such as Oil & Gas, water well , Construction,Mining, Horizontal Directional Drilling (HDD), Geothermal and Environmental. Our experienced staff is here to assist you with everything from choosing the right bit to shipping around the globe.
Our goal is to provide our customers with the best quality tools, accessories and service in the industry. We are supported by many years of experience, trained professionals and a full machine shop. Reduce the cost ,Speed the drilling ,Guarantee the safety is always our aim.
IADC | WOB | RPM | Applicable Formations |
(KN/MM) | (r/min) |
(Bit Dia) |
116 117 | 0.35~0.8 | 150~80 | Very soft formations with low compressive strength and high drillability,such as clay,mudston,chalk etc. |
|
126 127 | 0.35~0.9 | 150~70 | Soft formations with low compressive strength and high drillability,such as mudstore,gypsum,salt,softshale.soft limestone,ect. |
|
136 137 | 0.35~1.0 | 120~60 | Soft to mesium soft formations with low compressive strength and high drillability.such as medium soft shale,hard gypsum,medium soft limestone.medium soft sandstone soft formation with harder nterbeds,ect. |
|
216 217 | 0.4~1.0 | 100~60 | Medium hard formations with high compressive strength,such as medium soft shale,hard gypsum,medium soft limestone,medium soft sandstone,soft formation with harder interbeds ect. |
|
246 247 | 0.4~1.0 | 80~50 | Medium hard formations with high compressive strength,such as abrasive shale.limestone,sandstone,dolomite,hard gypsum,marble,ect. |
|
417 437 | 0.35~0.9 | 150~70 | Very soft formations with low compressive strength and high drillability,such as clay,mudston,chalk,gypsum,salt,soft shale,soft limestone,etc. |
447 |
517 527 | 0.35~1.0 | 140~60 | Soft formations with low compressive strength and high drillability,such as mudstore,gypsum,salt,soft shale.soft limestone,ect. |
|
537 547 | 0.45~1.0 | 120~50 | Soft to medium formations with low compressive strength,such as medium soft shale,medium soft limestone,medium soft sandstone,medium formation with harder and abrasiver interbeds,ect. |
|
617 627 | 0.45~1.1 | 90~50 | Medium hard formations with high compressive strength,such as hard shale,limestone,sandstone,dolomite,ect. |
|
637 | 0.5~1.2 | 80~40 | Hard formations with high compressive strength,such as sandstone,limestone,dolomite,hard gypsum,marble,ect. |
Hebei HengJi Drill Bit Manufacture Co., Ltd., as a leading manufacturer of tricone bit and PDC bits, our products are made strictly complying with API specifications and ISO9001.
Hebei HengJi Drill Bit Manufacture Co. Ltd was established in 1997. We have kept our clients ahead of schedule and under budget by providing the highest quality tools at the best possible prices.
We ship to more than 30 different countries and serve industries such as Oil & Gas, water well, Construction, Mining, Horizontal Directional Drilling (HDD), Geothermal and Environmental. Our experienced staff is here to assist you with
Everything from choosing the right bit to shipping around the globe.
Our goal is to provide our customers with the best quality tools, accessories and service in the industry. We are supported by many years of experience, trained professionals and a full machine shop. Reduce the cost, Speed the drilling, Guarantee the safety is always our aim.
