| Prod Model: |
HW80 |
| Part Name: |
Water Well Drilling Rig |
| Model Number: |
Hw-80 |
| Drilling Depth: |
60-150m |
| Maximum Open Hole Caliber: |
300mm |
| End Hole Caliber: |
70mm |
| Drill Rod Caliber: |
42mm |
| Drilling Angle: |
90~75 |
| Diesle Engine Power: |
76 HP |
| Price: |
Factory Price |
| Warranty: |
1 Year |
Product Description
80m depth Small Bore Well Drilling Machine for SaleProduction Features
1. Boreholes for agricultural irrigations and geothermal wells
2. Water supply for your house yard, gardens and farms;
3. Unique design and simple drilling structure;
4. Easy to transport and can learn how to handle the machine in short time;
5. Assure easily operation and long life span to save more labors and money for you;
Question and answer
1: What kind of drilling work can it do?
Mainly applies to drill wells for farm irrigation wells, garden irrigation wells, drilling water wells, geothermal wells.
2: What are the max. depth and the max. diameter of holes allowed for this drill rig?
250mm diameter and 150m depth are available. Here we sincerely inform that the final depth and diameter will subject
to your special local working strata and drilling experience.
3: What kind of working strata is OK ?
Soil, sandy, clay, sediment, soft rocks, etc. Certainly, the special strata need different drilling bits. Please note that this
model is not designed for drilling hard rocks
4: What is your advantage over this drill?
Economical and worthy to owned by any family.Practical and efficient by drilling speed of 40m/h;Easy operate and maintain by only two workers.
Technical Parameters |
Type |
HW-80 |
Max. Drilling Diameter |
70-300mm |
Max. Drilling Depth |
60-80m |
Total Power |
8.8 kw |
Engine Power |
1.2kw |
Lifting Power |
1.0kw |
Pump |
2.2kw,220V(flow head 46m) |
Capacity of hoist |
1.0t |
Height of tower |
3m |
Total Weight |
700kgs(150m pipes) |
Drilling Rod Length |
2m/piece |
Diameter of Drilling Rod |
42mm |
