| Prod Model: |
CPVC-F441001 |
| Standard: |
ASTM F441 |
| Material: |
CPVC |
| Hardness: |
Hard Tube |
| Type: |
Thermosetting Plastic Pipe |
| Hollow: |
Hollow |
| Shape: |
Round |
| Usage: |
Water Supply Pipe |
| Color: |
White or Gray |
Product Description
Jiangsu Huasheng Plastic Co., Ltd is one of the biggest PVC manufactuer in water supply field which has powerful abilities both in opening model and R&D
| Details Specification : |
| Items Name: | CPVC Pipe |
| Material: | PVC-C |
| Diameter : | 1/2 inch to 16 inch |
| Thickness: | 3.73mm ~ 21,41mm |
| Color: | Customize,Gray is normal color ,Orange PVC Pipe |
| Connection: | Glue connect ,Rubber with Gasket |
| Pressure: | High Pressure up to PN25 |
| Standard: | ASTM F441 |
| Certification: | ISO14001,ISO9001,CE,SGS,COC |
CPVC Pipe Advantage:
1. High Heat Resistance:allows transportation of hot liquid and high temperature chemicals below 93 degree celsius
2.Corrosion resistance: relatively inert with many chemicals
3.Heat insulation properties: 1/360 of steel pipes
4. Smooth wall surface: reduce invasion of microbes and other foreign particles
5. Compliance with the dissolution test: no effect on water quality
6. Electrical insulation properties: suitable for use as high voltage electrical power-lines
7. Cold bonding of cement allows simple and economical installation
| Standards of CPVC Testing Material |
| Index Name | Unit | Index |
| Density | kg/m3 | 1450-1650 |
| Vicat Softening Temperature | ºC | >=110 |
| Vicat Softening Temperature(Fittings) | ºC | >=103 |
| Longitudinal Reversion | % | <=5 |
| Chlorine Concerntration(Mass Percent) | % | >=60 |
| Hydrostatic Test | -- | No leafing,no break |
| Hydrostatic Reheat Test | -- |
| Drop Impact Test | -- | TIR<=10% |
| Oven Test | Cal/g/ºC | No lamination,no crack |
| Modulus of Elasticity | MPa | >=2660 |
| Tensile Strength | MPa | >=56 |
| Impact Strength | KJ/m2 | >=16 |
| Coefficient of Linear Expansion | m/mºC | 3.4×10-5 |
| Thermal Conductivity | Cal/g/ºC | 0.14 |
| Specific Heat | Cal/g/ºC | 0.14 |
| Bulk Resistance | Ω/cm | >=1015 |
| Dielectric Strength | AC,KV/mm | 13 |
| Flame Retardant | -- | Self-extinguish |
| (ASTM)CPVC PIPES SCH 80 |
| | | ASTM F441 | unit:mm |
| Size(") | Wall thickness | Outer diameter | Tolerance of wall thickness |
| 1/2" | 3.73 | Φ21.34 | 0~+0.51 |
| 3/4" | 3.91 | Φ26.67 | 0~+0.51 |
| 1" | 4.55 | Φ33.4 | 0~+0.53 |
| 1-1/4" | 4.85 | Φ42.16 | 0~+0.58 |
| 1-1/2" | 5.08 | Φ48.26 | 0~+0.61 |
| 2" | 5.54 | Φ60.32 | 0~+0.66 |
| 2-1/2" | 7.01 | Φ73.02 | 0~+0.84 |
| 3" | 7.62 | Φ88.9 | 0~+0.91 |
| 4" | 8.56 | Φ114.3 | 0~+1.02 |
| 5" | 9.52 | Φ141.3 | 0~+1.14 |
| 6" | 10.97 | Φ168.28 | 0~+1.32 |
| 8" | 12.70 | Φ219.08 | 0~+1.52 |
| 10" | 15.06 | Φ273.05 | 0~+1.80 |
| 12" | 17.45 | Φ323.85 | 0~+2.08 |
| 14" | 19.05 | Φ355.6 | 0~+2.29 |
| 16" | 21.41 | Φ406.4 | 0~+2.57 |
Our Services:
1. Any inquiries will be replied within 24 hours
2. Professional manufacturer.
3. OEM is available.
4. High quality, standard designs, reasonable&competitive price, fast lead time.
5. Faster delivery: Sample will be prepared in 2-3days.
6. Shipping: We have strong cooperation with DHL, TNT, UPS, MSK, China Shipping, etc.
7. You can also choose your own shipping forwarder
Jiangsu Huasheng Plastic Co., Ltd was founded in 1988, which specialized in moulding, Precision Injection, UPVC, CPVC pipe, fittings and Valves in DIN, ISO, ASTM standard on water supply and industry with NSF, CE, ISO, SGS etc certificates
Currently, the annual production has reached a sales turnover of USD 30, 000, 000, covering 250, 000 square meters of two factories, over 170 injection machines, 20 pipe extruding lines, 80 mechanical processing equipments and more than 500 laborers.
The annual production capacity has exceeded over 60, 000 tons and storage has been over 10, 000, 000 USD. Huasheng has already exported products to U. S. A, Japan, Korea, Dubai, Pakistan, India, Philippines, Turkey, Southeast Asia area, etc.
Jiangsu Huasheng Plastic Co., Ltd has been the expert in plastic industry for over 28 years, Huasheng is one of the biggest PVC manufacturers in water supply field who has powerful abilities both in opening model and R&D.
Now Huasheng is engaging in opening global markets. The team is powerful, possitive and professional.
We firmly believe one day, we will make our dream come ture.
