Automobile Steering Gear and Power Pump Test Bench
| Price: |
US $ 9000/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union |
| Prod Model: |
QFY-3 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Power: |
380V 50Hz |
| Motor Power: |
7.5kw |
| Update Method: |
by Hard Disk |
| Certification: |
ISO |
Product Description
QFY-3 Model Automobile Steering Gear and Power Steering Pump Test Bench1.Function Introduction
Automobile steering gear and power steering pump test bench is used for testing steering gears and power pumps of various models trucks.
This test bench possesses reasonable design, accurate test data and convenient operation.
It displays measured data by digital display instrument.
2.Test item:
- Pressure of power steering pump, can preinstall the rated pressure, automatic unloading
- Oil flow of power steering pump
- Revolving speed of power steering pump
- Input and output torque of steering gear
- Free stroke of steering gear
- Working angle of steering gear
- Performance of conversion valve assembly of steering gear
3.Technical Parameter
- Power: AC AC380V 50HZ (Made to order )
- Power of power pump motor: 7.5KW
- Frequency converter: 7.5KW
- Maximum working pressure of power pump: 25Mpa
- Angle measuring range of steering gear: ±90°
- Maximum torque of steering gear: Input 500N.M; Output 6000N.M
- Adjusting pressure of brake: 0--18 Mpa
- Speed: 0-2400r/min(frequency regulation) diversion: positive, reversal
- Heater power: 1000W 220V
- Rated heating temperature: 40ºC (adjustable)
Remark:
1.MOQ:1 set
2. panel: English
3.Delivery time:35 working days after downpayment
4.Payment term:T/T 50% advance, the balance 50% be paid before dispatch
5.Packing:
plywood box
1560*1050*1870mm=3.06CBM
N.W:720kgs
G.W:800kgs
6.HS code: 9031200090
