| Prod Model: |
YX MG1, MG12, MG13, MGS20 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Stationary Ring Materials: |
U2, Q2, V1, Q1 |
| Rotary Ring Materials: |
B, a, Q1, Q2 |
| Secondary Seal Material: |
V, P, E |
| Spring And Metal Parts Materials: |
F, G |
| Standard: |
Standard |
| Type: |
Mg1, Mg12, Mg13, Mgs20 |
Product Description
1.Operations Conditions:
Temperature:-20ºC to +120ºC
Pressure:≤1.2MPa
Speed:≤10m/s
2. Materials:
Stationary Ring:,Ni-binder Tungsten Carbide,Silicon Carbide Reaction Bonded,Ceramic(Alumina),Silicon Carbide Sintered Pressureless
Rotary Ring:Resin Impregnated Carbon Graphite(Furan),Antimony Impreg. Carbon Graphite,Silicon Carbide Sintered Pressureless,Silicon Carbide Reaction Bonded Secondary Seal:Fluorocarbon Rubber(Viton),Nitrile(NBR),Ethylene Propylene(EPDM)
Spring and Metal Parts:Stainless Steel.
3. Seat Types:
Standard:L01
Alternative:C01, C03, C06, L03
4. Applications:Clean Water,Sewage Water,Oil and other moderately corrosive fluids.
