| Prod Model: |
QND-316 |
| Product Name: |
High Performance Tungsten Carbide Saw Blade Sharpe |
| Usage: |
Cutting Hard Metal and Wood |
| Advantage: |
High Quality and Best Prices |
| Kind: |
Titanium Alloy Cutting Carbide Tipped Bandsaw Bla |
| Carbide Saw: |
Metal Cutting Band Saw Blades |
| Type: |
Tungsten Crucibles |
Product Description
High performance tungsten carbide saw blade sharpening machines cutting toolsKunshan Jenada Machinery Co.,Ltd. is a professional enterprise in cutting tool production and sales.Our company specializes in manufacturing sphpiscated Bimetal band saw blades series,Carbide tipped bandsaw blades and Food bandsaw blades Series. It relies on the good quality and advanced machining technology which owns special patent of bi-metal bandsaw blade. What's our products' advantage is the bandsaw blade will be better on abrasion performance,on red hardness, on fatigue resistance, on life span and on price.
Specifications
Teeth forms |
3/4 |
2/3 |
1.4/2 |
1/1.5 |
1.7/2.5 |
0.75/1 |
0.75/1.25 |
| 27mmx0.9 | OK | OK | | | | | |
| 34mmx1.1 | OK | OK | | | | | |
| 41mmx1.3 | OK | OK | OK | OK | OK | | |
| 54mmx1.6 | OK | OK | OK | OK | OK | OK | OK |
| 67mmx1.6 | OK | OK | OK | OK | OK | OK | OK |
| 80mmx1.6 | OK | OK | OK | OK | OK | OK | OK |
The choice for the tooth angle
| Front Angle | The range of the cutting material | Steel types | Note |
| 0° | 1.the profile angle is bigger and the strength is higher, so it's suitable for cutting different kinds of the material |
| It's better to choose the bigger front tooth agnle when the stiffness for the procee system is poor or the power for the saw machines is shortage |
| 0°~5° | 1.suitable for cutting brittle materials; | Such as: gray cast iron,
High speed steel and chilled cast iron, tool steel, alloy steel, spring steel, high quality carbon structural steel, bearing steel, steel, martensite stainless steel and heat resistant steel
(HT200,65Mn,W18Cr4V,T12,50Cr,60Si2MnA,1Cr12,1Cr13,GCr15) |
| 2.suitable for cutting hard material; |
| 3.Suitable for interrupted cutting or the forging ,casting with crustaceous; |
| 4.applicable to small section,thin walled pipe |
| 6°~10° | 1.applicable to the workpiece material strength,low hardness, and good plasticity | Such as: ordinary carbon structural steel, high quality carbon structural steel, alloy steel, carbon tool steel and austenitic stainless steel, nodular cast iron, nonferrous metals
(Q235-A,20,30,45,T10,40Cr,20CrMo,1Cr18Ni9Ti,Cu
And so on) |
|
| 2.suitable for cutting solid material,thick walled pipes |
Kunshan Jenada Machinery Co., Ltd. is a professional enterprise engaged in cutting tool production and sales. Our company specializes in manufacturing sophiscated Bimetal band saw blades series, Carbide tipped bandsaw blades and Food bandsaw blades Series. We provide customers with products of excellent quality at a competitive price.
For the Bi-metal bandsaw blades, the teeth are welded using cobalt-alloy with hardness reaching HRC69-70. M51 Tooth and Substrate jointing by laser after separately special spring steel heat treatment. Tooth's rigidity and Substrate's intension exert their use to the extreme. This saw is suitable for cutting Heat-resisting alloyLow-carbon stee\Medium carbon steel, High-carbon steel and Non-ferrous metal. Which results in cost saving and improves cutting efficiency.
Besides, We are currently highlighting our meat-cutting division, with the use of Japan's and Switzerland's Stainless Steel SK4, tolerance milling, the teeth of our blade saws are strengthened and meat scraps in the cutting process can consequently avoided. Additionally, the world class technique of precise milling and UHF tooth quenching are employed in the process, producing saw blades with superior hardness and sharpness. They are suitable to use in processing plants of meat, fish, poultry, and the cutting of frozen fresh meat in supermarkets, restaurants, etc.
Our target is to devote our effort to develop new products; Improving productivity and supply advanced technologies to enhance customers' benefit and requrirements.
