Class 10.9 Steel Hex Head Screw for Machine

Prod Model:	LKTL
Sample:	Free (If in Store)
Market:	Global
Optional Material:	Stainless Steel, Carbon Steel, Alloy Steel, Brass
Optional Properties:	A2/4-50/70/80, Class 6.8/8.8/10.9, Grade 2/5/8....
Optional Finish:	Zinc, HDG, Magni, Geomet, Dacromet, Passivate.....
Optional Size:	M6 to M36, or 1/4" to 1-1/2"
Material:	Carbon Steel
Type:	Hexagon Head
Connection:	Common Bolt
Head Style:	Hexagonal
Standard:	ISO
Grade:	10.9
Finish:	Plain

Product Description

Class 10.9 Steel Hex Head Screw for Machine
1> Decription: Class 10.9 Steel Hex Head Screw for Machine
2> Material: Carbon Steel
3> Surface: Plain
4> Size: M6 to M36, 1/4" to 1-1/2"
5> Length: Up to 500mm
6> Mechanical Properties: Class 10.9
7> Packing: Bulk packing and box packing







We professionally produce bolts such as Hex head screw, carriage bolt, square head bolt etc. The product standard contains DIN, GB, ANSI, ISO, JIS. Imported equipments, materials and matrixes are used in the company. We also make high quality product which is not standard.

Please feel free to contact us if you are interesting our products. We are strongly believe will guarantee you the best quality and service for our more than 30 years professional experience.

Technical Delivery Conditions
Material		Steel	Stainless steel		Non-ferrous metal
General requirements		As specified in DIN 267 part 1
Thread	Tolerance	6g
	Standard	DIN13 Part 12 & 15
Mechanical properties	Property  class	5.6 8.8 10.9	≤M20	A2-70	Subject to agreement
				A4-70
			>M20	A2-50
				A4-50
				C3,C4
	Standard	ISO 898 Part 1	DIN267 Part 11		DIN267 Part 18
Limit deviations geometrical tolerance	Product grade	A for product up to size M24 and L≤10d or 150mm B for product exceeding size M24 or L>10d or 150mm
	Standard	ISO 4759 Part 1
Surface finish		As processed Property class 8.8 and above: Blackened	Bright		Bright
		DIN267 Part 2 shall apply with regard to surface roughness
		DIN267 Part 19 shall apply with regard to permissible surface discontinuities
		DIN267 Part 9 shall apply with regard to electropiating
		DIN267 Part 10 shall apply with regard to hot dip galvanizing
Acceptance inspection		DIN267 Part 5 shall apply with regard to acceptance inspection

Q&A

Who Lockey is?
A fastener manufacture founded in 1973. Dragon Iron Group devotes itself to the manufacture and sales of fasteners, hardware parts, forging and machine parts for Auto and other industries.
Dragon Group has its headquarter, Dragon Iron Enterprise, in A Lien, Taiwan.
Lockey Industrial Co., Ltd. set up in 2003 in Dongguan City to be the Foreign Sales Department of the group. Our plant was established in Jingjiang City. In that way, we can easily export our products .

What Lockey does?
As a fastener manufacture, we mainly produce including, but not only:
1. Bolt, studs, and thread rods...
2. Hex nut, nylon nut, flange locknut...
3. Tapping screw, drilling screw, wood screw, machine screw, socket cap screw...
4. Plain washer, spring washer, tooth washer...
5. Structural applications, ASTM A325/A490, ASTM F1852/2280, DIN6914/5/6, DIN7990...
Meanwhile, special fasteners, hardware parts, forging and machine parts for Auto are also in our range. We make parts for Toyota, Honda.
70% of our products are exported.

Why Lockey?
Lockey never stops doing one thing: INNOVATE. Innovation is the permanent power for the development of Lockey. Technology innovation and concept innovation, keep Lockey going well and going further. Meanwhile, Lockey gathered a group of talents who good at management and co-operation. Go and contact with these professional man, you will get a satisfied result.
We are glad that you choose Lockey as your supplier, but Lockey more than a supplier. We are partner. We do not only sell, we share. Share the newly info of fastener, price trend...we also share profit.
We are friend. We do not only care our sales, but also yours; and the quality in using.

What Lockey do to assure the quality?
As a over 40 years experience in fastener manufacture with ISO9001 certificate, we meet difficulties or problems, and we solve them all ways. Lockey set up a quality assurance system according to ISO9001 with the 40 years experience. Criteria were made on factors that may effect the quality. 80% of our staff are skilled, and have worked in Lockey for more than 5 years, employee have to take skill class on/off work for weeks. All of these is to guide our worker how to prevent and handle an issue.

Do Lockey produce non-standard item?
Yes, we do. Send your specification drawings to our sales representative, then you will get a quotation.

Do lockey have a published price list?
We do NOT have a published price list. In our business market conditions are always fluctuating, which makes standard pricing difficult to maintain. We allow our sales staff to be flexible when it comes to quoting on your requirements, which means that you will receive the best pricing available when you need it.

Do Lockey offer a discount?
Of course. we can offer you a discount base on your large quantity. But at the same time, like what we said above, we believe our sales staff have offered you the best price. In that way, you may have a discount, but not a big one. Go and explore for it.

Do Lockey provide samples?
Why not, and stored samples are totally free. What we are going to tell you is that we do NOT have budget for Express.

What's the delivery time?
It depends on your order quantity. It is about 20-40 days for standard ones, 35-60 days for non-standard ones. Check it with sales representative, he/she will give a accurate date of shipment.

What is the payment term?
T/T & L/C are the prefer payment term. Also Western-Union is acceptable for low value payment, like samples' Express fee.
