CNC Diamond Wire Saw Granite Marble Stone Cutting Machine

CNC Diamond Wire Saw Granite Marble Stone Cutting Machine
Price: US $ 29500-42500/Piece
Min Order: 1/Piece
Pay Type: T/T,Western Union
Prod Model: GBSJ-1500
Function: CNC cutting machine
Operation: Auto and easy
Main Motor: 15.09kw
Key Word: diamond wire saw
Control System: CNC
Color: customer needing
Type: CNC Cutting Machine
Usage: Marble
Application: Stone Industry
Source Voltage: 380V
Automation: Automatic

Product Description

GBSJ-1500 CNC Wire Saw Machine

Features:
  1. The degree of automation is high. The electrical system adopts the CNC technician; the main running adopts the stable, good quality and strong servo motor. The running of the wheel adopts the stepping motor.
  2. The structure is reasonable, the running is stable. The main frame is gantry type. And because the up/down of the two flywheels adopt the roller type structure, the up/down action is light and flexible, stable. The wire wheel is through balance adjustment so its work is more stable. The up/down is controlled by separate stepping motors, so it is easy for adjustment and easy to keep in the same height.
  3. The operation is easy. It adopts the man-machine menu which is easy for reading and monitoring. Design the shape on the computer and then copy it to this system. It will change it into the procedure directly.
  4. The tension of the wire adopts hydraulic system. This hydraulic system is designed with the hydraulic accumulator and discharge pressure switch which can make sure the stable pressure and is easy for maintance.
  5. It is major in profiling processing of the granite and marble, can cutting different sizes of arc slab, solid columns and hollow columns and large-scale stone line, letter etc.
Technical data:
NameUnitGBSJ-1500GBSJ-1800
Saw diametermmΦ8-Φ10¢8-¢10
Saw gross lengthmm1730019300
Line speedm/s0-350-35
Lifting travel of cuttermm16001900
Max process sizemm3500X2000X15003600*2000*1800
Production efficiencym2/h1-2 (marble)
0.5-1 (granite)
1-2(marble)
0.5-1(granite)
Full sizemm8200×6000×3800 8800×6800×4800
Main motorkw1111
Gross powerkw19.3819.38
Gross weightkg70009000
Worktable whether revolve nono
Worktable sizemm1350*20001800*2000
Guide wheel diametermm200200






Great Base, was founded by a experienced and professional team, all the members are the export in Chinese Stone Machinery Industry, Diamond Tools Industry, Stone Industry.

Though Great Base is very young, she is rapidly becoming known as a professional and reliable company within the Stone Industry of China and abroad.

The Head Office of Great Base is located in Xiamen known as today's "Capital of the international market for natural stone". Our own stone machine factory is located in, Xiang'an industry, Xiamen, we can produce series Stone Processing Machine, such as GBQS series Block Cutter, GBQQJ series Bridge Type Block Cutter, GBHW series Laser Bridge Edge Cutter, GBLXM series Granite Polishing Line, GBMM series Marble Slab Polishing Line, GBSJ series CNC Wire Saw/ Block Cutting Wire Saw, GBXJ series Automatic Profile Saw, GBYZ series Column Cutting Machine, and so on. All machines are improved based on current machine in China because of all the technician/managers with more than 20 years working experience in Stone Machine industry. We know what kind of quality/price/service we need provide for our abroad clients, and hope long term cooperation. At this moment our machines are working in USA, Canada, Australia, Bulgaria, Russia, Ukraine, Moldova, Kyrgyzstan, Armenia, Saudi Arabia, Egypt, Dubai, Oman, Sudan, Uganda, South Africa, Vietnam and other places, We also participate in Coverings in USA Apirl, Dubai Stone Fair in May, Moscow Stone Fair in June, Cairo Stone Fair in DEC. We also have already several partners in different countries.

Any inquiry, any question, please call/email us, and we also warmly invite you to visit us, Great Base looks forward to cooperating with you and building a better future together.
