| Price: | US $ 2880-3500/Piece |
|---|---|
| Min Order: | 1/Piece |
| Pay Type: | L/C,T/T,Western Union,Money Gram |
| Prod Model: | VTF |
|---|---|
| Reject Optional: | Push Rod and Flap Drop |
| Material: | Stainless Steel |
| Optional: | Digital or Analogy Choose |
Self-frequency adjustment .Enjoys a variety of operating frequency, According to products style self automatic adjustment.stable features.
self-learning function and high sensitivity.can recognize different kinds of products.
Can store and records about 100 product parameter data .easy for different production line shift
Can according to customer production line design the belt height so achieve butt-joint to
other equipment
Two digital collection line keeps it good performance .
Full Digital touch screen help it is easy to operate .
Special design for strong anti-interference function for harsh production environment
High standard shake-proof .water-proof keep it super performance and long service life.
Improve design keep it Zero wrong alarm when tap the probe.
succinctly detachable framework design let it easy for the operators to clean the equipment.
General specification :
Reject system :
Standard layout :Automatic stop by alarm and so on
Optional :Air blast (Especially for light food, like instant noodle.Small punches.)
Optional:Push rod(Especially for middle bag,small box.small container and so on)
Optional :Fall drop(Especially for some grain.nut.granule .and so on unpack products)
Application :
Food industry
Medical industry
Food additives
Baby products
Health products
Other industry that need reject and detect metals
Standard replace use Layout parts :
One set of hex wrench
Full sets of the range calibration test cards(Ferrous,non-ferrous ,Stainless steel)
Warranty
12month labor and parts
Full life technical support
Packing and shipment
Full machine takes of two layer package
Prepackage takes of plastic bags conveyor the full machine and the key parts have foam plastic protection
Eng package takes of Strong ploy wooden case that meet different country import standard
Installation and use
When you takes of the package .up the rubber base ,use wheel move it to your work place.
Then down the rubber base and fasten it..keep all the base in a horizontal
Then running the machine few hours before use ,No need complex installation .
The user guide will make in book and Videos for customer reference .
Sensitivity reference
| Details Tunnel size | 40*12cm | 40*15cm | 40*20cm | 50*15cm | 50*20cm | 50*25cm | 50*30cm |
| Sensitivity Fe(mm) | 0.8 | 1.0 | 1.2 | 1.0 | 1.2 | 1.5 | 2.0 |
| Sensitivity SUS(mm) | 1.5 | 2.0 | 2.5 | 2.0 | 2.5 | 3.0 | 3.5 |
| Detection height | 120 | 150 | 200 | 150 | 200 | 250 | 300 |
| Detection width | 400 | 500 | |||||
| Belt speed | 10-35 meters per minute adjustable | ||||||
| Alarm method | Light and sound and optional reject | ||||||
Power supply: AC110V.220V or 380V, 50-60Hz.
we takes of ploywood case that suitable for export
Shipment according to customer can by air by sea or by railway station
our sales team can give feedback within 12 hours after receive your inuiry
our after sales team can give solution within 48 hours after receive your request
our engineer can go aboard for technical support for big project depends
we are a professional metal detector manufacture
we accept kinds of metal detector customized
1. Are you manufacturer or trader?
We are manufacturer, we have own factory in Dong Guan, we have independent department for purchasing, producing, processing, testing, packing, storing , and transportation, believe our team is best team in china.
2. Do you sell the accessories for Products ?
Yes. We have Match the parts for our testing equipment. If our machines damages by fire, water flood, earthquakes, unsteady of power and other natural disasters, we are willing supply match parts with lowest price for you.
3.How about the packing for product? Is it easy damaged during transportation?
For light structure products like Gold detector. Hand held metal detector and so on we takes of strong carton box .
For heavy structure products like conveyor belt needle detector. Food metal detector X ray machine .Our packing is Standard Export ploy Wooden Case.
Every prepackage have a plastic bags cover .
4. What's your main product?
We professional in needle detector. Metal detector. X ray machine and other related electronic products and machines
5.Where is your main sales market?
Our Gold meal detectors customer all over the world.
Our hand metal detector and walk through metal detector mainly in Southeast of Asia.
South of America.Middle east. East Europe and Africa
Our needle and food metal detector mainly customers are from Australia. USA. All Europe and Asia
6.How about your after-sales policy?
Customer first is our always principle . All of our products normal warranty is 12months. We give necessary back or video guidance for daily problems. If massive products occur big quality problems. Our technical and engineer support overseas service .
7.Do you accept customer Logo and customized ?
we accept kinds of customized and logo of all of our products for customers
