Dd703 High Speed Economical Hole Drilling Machine From Abby
| Price: |
US $ 5000/Set |
| Min Order: |
1/Set |
| Pay Type: |
L/C,T/T |
| Prod Model: |
DD703 |
| Machine Weight: |
700kg |
| Power(W): |
3kw |
| Voltage: |
380V/50Hz |
| Filtering Model: |
Shallow Seam Type |
| Spindle Travel: |
200mm |
| Usage: |
Metal Parts |
| Water Tank: |
25L |
| Z-Axis Travel By Motor Drive: |
280mm |
Product Description
Technique Machine
High speed economical hole drilling machine
| Technical parameter/Model | unit | DD703 |
| Worktable size | mm | 320x440 |
| Worktable travel | mm | 200×300 |
| Z-axis travel | mm | 280 |
| Max.load on table | mm | 200 |
| Main spindle speed | rpm | 60 |
| Diameter of electrode | mm | φ0.3-φ3 |
| Max.distance from guider to worktable | mm | 240 |
| water tank | L | 25 |
| Filtering model | | shallow seam type |
| Working medium | | water |
| MAX.working pressure | Mpa | 7 |
| Power supply | | 380V,3Ph,50Hz |
| Max.woking current | A | 30 |
| Power consumption | Kw | 3 |
| Machine weight | kg | 700 |
| Machine demensions | mm | 1060×750×1700 |
