| Prod Model: |
DB-series |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Usage: |
Drilling, Engineering Material |
| Model: |
dB Series |
| Working Length: |
400mm |
| Thread: |
1-1/4unc |
| Use: |
Concrete Drilling |
Product Description
This diamond core drill bit has excellent ability in drilling concrete, reinforced concrete and brick wall. Thinner
Diamond segment and thinner tube wall can easily reduce the resistance and increase the drilling speed. It may be sold separately or with core drilling machine.
Feature:
1. Thinner diamond segment and thinner tube wall can easily reduce the resistance and increase the drilling speed.
2. Very fast cutting speed and low cutting pressure.
3. Different connection end for different drilling machine.
4. Especiall effective in drilling through reinfored concrete
5. The diameter of them can be produce according to the requirment of users, the main dimensions are as follow table.
Model No. | Diameter | Working
Length | Seg. Nr. | Segment size | Thread |
| DB042 | 42mm | 400mm | 5 | 15x3.5x8mm | 1-1/4UNC |
| DB051 | 51mm | 400mm | 5 | 24x3.5x8mm | 1-1/4UNC |
| DB056 | 56mm | 400mm | 5 | 24x3.5x8mm | 1-1/4UNC |
| DB063 | 63mm | 400mm | 6 | 24x3.5x8mm | 1-1/4UNC |
| DB066 | 66mm | 400mm | 6 | 24x3.5x8mm | 1-1/4UNC |
| DB076 | 76mm | 400mm | 7 | 24x3.5x8mm | 1-1/4UNC |
| DB083 | 83mm | 400mm | 7 | 24x3.7x8mm | 1-1/4UNC |
| DB089 | 89mm | 400mm | 8 | 24x3.7x8mm | 1-1/4UNC |
| DB102 | 102mm | 400mm | 9 | 24x4x8mm | 1-1/4UNC |
| DB108 | 108mm | 400mm | 9 | 24x4x8mm | 1-1/4UNC |
| DB112 | 112mm | 400mm | 9 | 24x4x8mm | 1-1/4UNC |
| DB120 | 120mm | 400mm | 10 | 24x4x8mm | 1-1/4UNC |
| DB127 | 127mm | 400mm | 11 | 24x4x8mm | 1-1/4UNC |
| DB132 | 132mm | 400mm | 11 | 24x4.5x8mm | 1-1/4UNC |
| DB152 | 152mm | 400mm | 12 | 24x4.5x8mm | 1-1/4UNC |
| DB160 | 160mm | 400mm | 12 | 24x4.5x8mm | 1-1/4UNC |
| DB165 | 165mm | 400mm | 12 | 24x4.5x8mm | 1-1/4UNC |
| DB172 | 172mm | 400mm | 12 | 24x4.5x8mm | 1-1/4UNC |
| DB178 | 178mm | 400mm | 13 | 24x4.5x8mm | 1-1/4UNC |
| DB180 | 180mm | 400mm | 13 | 24x4.5x8mm | 1-1/4UNC |
| DB182 | 182mm | 400mm | 13 | 24x4.5x8mm | 1-1/4UNC |
| DB186 | 186mm | 400mm | 13 | 24x4.5x8mm | 1-1/4UNC |
| DB200 | 200mm | 400mm | 15 | 24x4.5x8mm | 1-1/4UNC |
Packaging & Shipping
Package: Carton package
Shipping: by sea, air, or DHL/TNT/UPS Express
Our Services
With a commitment to quality and professional service, the company has gained acceptance as a supplier, with more than 300 clients including many of the major companies around the world. Our main customers are private and research testing laboratories, road and general contractors, concrete and cement manufacturers, asphalt manufacturers, government authorities, ministries, engineers, consultants and re-seller. We also cooperate with accredited research centers and the most important universities in the world.
Tianpeng competitive advantage is seen as:
To provide top quality products at a fair price supported by a team of competent, efficient and professional sales.
Company Information
ZhuozhouTianpeng imp. and exp. Trade co., ltd is founded in 2006, and specialize in the design, manufacture and supply of high quality construction materials testing equipment for concrete test, soil test, cement test, asphalt test and etc. Our main products include compression test machine, wheel tracking machine, roller compactor, test mould and etc. There are about hundred products of seven series.
Tianpeng logo is branded and internationally qualified and the company image is well known worldwide. We believe that we can supply more top quality product and service for more customer's trough our further effort in near future.
