| Prod Model: |
diamond profiling grinding wheel |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Product Name: |
CNC Wheels |
| Application: |
Granite, Basalt, Sandstone, Marble Ect. |
| Price: |
Competitive and Best Price |
| Quality: |
High Performance |
| Bond: |
Diamond and Metal |
| Grinding Life: |
Long |
| Sharp: |
All Kind Sizes Are Available Upon Request |
| Material: |
Diamond and Metal |
| Use: |
Stone Profiling |
| Feature: |
Precise Profiling |
| Graininess: |
150# |
| Thickness: |
18mm |
| Kind: |
Diamond Wheel |
| Manufacturing Arts: |
Sinter |
| Usage: |
Stone Cutting, Plastics, Laminate Plate, Semiconductor Cutting, Lab Use Super-thin Saw Blade, Optical Glass Cutting, Abrasive and Carving, Fire-Retardant, Porcelain, Drilling, Arts Cutting, Engineering Material, Stone Edge Profiling |
| Brand: |
Wanlong |
| Saw Blade External Diameter: |
Dia.10-380 |
| Specification: |
5inch |
| Customized: |
Customized |
Product Description
CNC WHEEL
Brief introduction: CNC Profiling wheel are equipped on the CNC stone processing machine. Precise profiling, high effecieny, it is widely used in the edge processing of vanity top and counter-top etc.
1) Applicable for special shape stone processing.
2) Diameter 120mm- Bore 35mm (smaller diameters available on demand).
3) Thickness of processed stone 20-60mm.
*For other specification and sizes are availble upon request.
| Position | Type of Working Layer | Grit | Working Procedure |
| Pos. 0 | Metal Sintered, Segmented | 30,40 | Roughing |
| Pos. 1 | Metal Sintered, Segmented | 30,40 | Shaping |
| Pos. 2 | Metal sintered, Continous | 70,80 | Coarse profiling |
| Pos. 3 | Metal sintered, Continous | 140,170 | Medium finishing |
| Pos. 4 | Metal sintered, Continous | 230,270 | Finishing |
| Pos. 5 | ABR hot pressed, Continous | 400 | Good finishing |
| Pos. 6 | ABR hot pressed, Continous | 800 | Polishing |
| Pos. 7 | ABR hot pressed, Continous | 1500 | Polishing and Buff |
| Pos. 8 | ABR hot pressed, Continous | 3000 | Polishing and Buff |
Fujian Diamond Tool Co., Ltd. Was established in 1998, with imported advanced technology and cutting grinding machines, firstly cuts stone into 3-5mm laminated with Aluminum and Aluminum Honeycomb. This opens a new stage of stone building material industry in our country. With our great efforts and full experiences to improve our technology, we are successfully reduced the cost and promoted this kind of products to international market. Our annul output of Stone Panel reach 50000 square meters, and it has met good demand in USA, Europe, and Korea, etc. Recently, we newly use the Stone panel made into stone table top Panel, Stone countertop panel. We have been in a constant pursuit of enterprise spirit "Creative, Enterprising" redoubling our efforts for further im provements of innovations, we have created a new landmark in stone industry.
In the United States has an excellent and very professional exclusive partner SPI, and SPI just like a big family, they are working together with American people and helping them design wonderful, gentle and graceful homes...Any friends who from USA are interested in our products, please not hesitate to contact with our exclusive partner SPI in the United States, Surely SPI will take care of all your requests and supply you a very wonderful service.
Now is looking for agents in others countries, welcome you to join us and create a very wonderful future together.
