Prod Model: |
SY-DW-1000 |
Markets: |
North America,South America,Southeast Asia,Africa,Mid East |
Bead Diameter(mm): |
7.2 - 11.5 |
Bead Number(mm): |
37/40 |
Line Speed: |
18 - 38 |
Fixing Method: |
Rubber/Plastic, Rubber+Spring |
Cutting Speed: |
0.5 - 10 |
Life Span: |
0.5 - 45 |
Certifcate: |
ISO, BV, ISO 9001:2008 |
Model No.: |
S-Dws-1041 |
Port: |
Xiamen/Guangzhou Port |
Kind: |
Stone Sawing Machine |
Manufacturing Arts: |
Sinter |
Usage: |
Stone Cutting |
Graininess: |
Success Formula for Stone Concrete Cutting |
Thickness: |
Diamond Wire |
Shape: |
Diamond Wire |
Brand: |
Sunny |
Saw Blade External Diameter: |
Diamond Wire |
Product Description
Diamond Wire for Granite Block Profiling
Besides Premium Quality Granite Diamond Wire For Granite And Sandstone, we also produce following type:
Diamond wire for marble cutting
Diamond wire saw for granite quarry
Diamond wire saw for marble
Diamond wire saw for cutting reinforced concrete
Multi wire saw
1. Use for Granite/sandstone cutting.
2. High quality cable insure less breakage and good tension.
3. Keep Sharp and long life
4. Original Rubber/plastic bring better performance in tough environment
Description:
Diamond wire-saws are widely used for granite quarries. The main specialties of diamond wire-saws are:
· To be able to used for great area granite quarries cutting
· To get high percentage of forming dimension stone
· High manufacture efficiency
· Safety, low- noise, no- dust and friendly surroundings
· Low cutting cost.
The advantage of rubber wire saw for granite quarry:
1. The rubber adheres better to the beads and support cable, which protects it better from the action of abrasive pastes, in particular when the cable takes up small radii of curvature (beginning and end of quarry cuts).
2. The rubber easily withstands increases in temperature caused by badly controlled water spraying, which often happens in a quarry, whereas plastic softens and losses its strength properties.
3. The flexibility of a cable fitted with rubber is greater, which reduces the risk of irregular wearing of the beads (ovalisation phenomenon).
37-75KW wire saw machines are more used for granite quarry, the water spraying between 25-50 L/min according to the cut dimension.
Recommendations:
· The rotation of the wire should be regularly checked.
· The worn condition of beads should be regularly inspected.
· The worn condition of connections & the beads near connections should be regularly checked. Change connections when it's needing.
· The cable tension is set in 250-300kg(Φ 4-5mm cable).
· Adjust the linear speed of the wire according to the material being sawn:
· During the sharpening of a new wire, the liner speed should be reduced 2-3 m/s from the above standard.
· Water requirement is between 15-25L/min.
Kindly Noted, when place order please inform the following:
Diameter of the Wire
Wire Type (rubber or rubber+spring)
Granite Type (Hard, Medium, Soft, or Abrasive)
Quantity (How many Meters)
Wire Saw Machine Power (How many KW or HP of the motor)
Expected cutting speed and life(M2)
Expected shipping date
Bead Diameter | Beads/Meter | Fixing Method | Application | Line Speed | Cutting Speed | Wire Life |
Ø11.5 | 40 | High quality rubber | granite quarry | 24~28 | 4~8 | 8~18 |
Ø11.0 | 40 |
Ø11.0 | 37 | High quality plastic | granite squaring | 24~28 | 5~7 | 12~20 |
Ø10.5 | 37 |
Ø11.0 | 40 | High quality rubber |
Ø10.5 | 40 |
Ø9.0 | 37 | High quality plastic | granite profiling | 24~28 | 3~4 | 10~14 |
Ø8.5/8 | 37 |
Other specifications are available upon requirement. |
Bead Diameter | Beads/Meter | Fixing Method | Application | Line Speed | Cutting Speed | Wire Life |
Ø11.5 | 28-32 | Spring connection | marble quarry | 33~38 | 5~8 | 30~45 |
Ø11.0 |
Ø11.0 | 37 | High quality plastic | marble squaring | 30~35 | 8~10 | 30~40 |
Ø10.5 | 37 |
Ø9.0 | 37 | High quality plastic | marble profiling | 30~35 | 8~10 | 25~40 |
Ø8.5/8 | 37 |
Other specifications are available upon requirement. |
Bead Diameter | Beads/Meter | Fixing Method | Application | Line Speed | Cutting Speed | Wire Life |
Ø11.5 | 40 | Rubber+Spring | Highly Reinforced concrete | 20~22 | 0.8~2.0 | 1.0~2.5 |
Ø11.0 |
Ø10.5 |
Ø11.5 | 40 | Rubber+Spring | Normally Reinforced concrete | 22~25 | 2.0~5.0 | 2.0~7.0 |
Ø11.0 |
Ø10.5 |
Ø11.5 | 40 | Rubber+Spring | Steel/Metal structure | 18~20 | 0.5~1.0 | 0.5~1.2 |
Ø11.0 |
Ø10.5 |
Other specifications are available upon requirement. |
Bead diameter | Beads/Meter | Fixing Method | Application | Line Speed | Cutting Speed | Wire Life |
Ø9.0 | 37 | High quality plastic | Hard granite | 20~25 | 1~2 | 8~12 |
Ø8.5 |
8 |
7.2 |
Ø9.0 | 37 | High quality plastic | Mid-hard granite | 22~26 | 2~3 | 10~15 |
Ø8.5 |
8 |
7.2 |
Ø9.0 | 37 | High quality plastic | Soft granite | 24~28 | 3~5 | 12~20 |
Ø8.5 |
8 |
7.2 |
Other specifications are available upon requirement. |
QUANZHOU SUNNY SUPERHARD TOOLS Co., Ltd is a professional and Dynamic Diamond Tools manufacturer, established in 1993, Located in Quanzhou, Fujian province, China, factory covering 15000 square meters. Our technical department is composed of experienced professors and engineers. We devote ourselves to researching and manufacturing cutting and processing Diamond tools for nature stone and building materials. Our tools are exported to more than 60 countries, including America, Brazil, Italy, Russia, Ukraine, India, Egypt, South Africa etc.
Main Products:
Cutting Tools (Saw blade, Segment, Wire saw etc)
Grinding&Polishing Tools (Calibration Rollers, Fickerts, Frankfurt, Cup wheel, Profilling wheel, Polishing pad, brush etc)
Drilling Tools (Finger Bit, Core drill etc)
The Philosophy of Sunny is "Superior product and service derived from standard and efficWe have a high efficiency team, each department strictly comply with company regulations.
From receiving your enquiry, put order in production and Dispatch to after-sales service, Ient management. "
In order to provide customer most suitable tools, we keep researching and analysing nature stone and engineering material. We cooperate with stone factory to test tools, and keep close contact with our customers by visit or communication to get knowledge of market demand.
We Response All Your Request efficiently To Save Your Time And Provide Your Utmost Convenience.
The deep understanding for customer's demand and strict quality control help us developing quickly, we wish to get your collaboration to achieve our objectives together!
Our aim is to provide our clients stable and consistant quality with competitive price.
Advantages enable clients benefits from our tools.
1. Experienced bond system
2. Advanced equipment and high grade raw material
3. Strictly production procedures control and quality inspection.
4. Customer's active feedback and support help us developing fast.
