DIN1480 / Us / JIS / Commercial Type Wire Rope Turnbuckle
| Price: |
US $ 0.084-0.1/Piece |
| Min Order: |
500/Piece |
| Pay Type: |
L/C,T/T,Western Union,Paypal |
| Prod Model: |
Turnbuckle |
| Type: |
Eye$Eye, Hook&Hook, Eye&Hook |
| Product Name: |
Wire Rope Turnbuckle |
| Materidal: |
Cast Iron Steel Stainless Steel etc |
| Size: |
5mm-40mm |
| Surface: |
Galvanzied,H.D.G. |
| Material: |
Steel |
| Usage: |
Turnbuckle |
Product Description
DIN1480 / US / Commercial Wire Rope Turnbuckle
Turnbuckle, rigging hardware, rigging screw, din1480 turnbuckle hook/hook,hook/eye, eye/eye, jaw/jaw.
DIN1480 / US / Commercial Wire Rope Turnbuckle - Rigging Hardware Supplier
- Qingdao Yanfei Rigging Co.,Ltd
| mension | Permissible Load | | |
| D | weight | 11 | m | 12 | b | di | da | i |
| mm(inch) | ,kg | N | kg/100pcs | mm | mm | mm | mm | mm | mm | mm |
| M6 | 230 | 2250 | 7.8 | 110 | 10 | 60 | 53 | 10 | 20 | 4.5 |
| M8 | 418 | 4100 | 14.8 | 110 | 14 | 60 | 55 | 12 | 26 | 6.5 |
| M10 | 663 | 6500 | 29.4 | 125 | 20 | 65 | 60 | 14 | 30.5 | 8 |
| M12 | 948 | 9300 | 36.3 | 125 | 21 | 75 | 70 | 18 | 37.5 | 10.5 |
| M16 | 1804 | 17700 | 91 | 170 | 27 | 100 | 90 | 22 | 48 | 13 |
| M20 | 2752 | 27000 | 156 | 200 | 34 | 115 | 100 | 25 | 51 | 20 |
| M24 | 3996 | 39200 | 325 | 255 | 39 | 140 | 130 | 28 | 66 | 27 |
| M30 | 6371 | 62500 | 415 | 255 | 45 | 145 | 130 | 35 | 83 | 31 |
| M32 | 6585 | 64600 | 595 | 295 | 55 | 160 | 150 | 36.5 | 88 | 33 |
| M36 | 9276 | 91000 | 745 | 295 | 55 | 160 | 150 | 44 | 104 | 40 |
| M38 | 9572 | 93900 | 1076 | 330 | 63 | 185 | 170 | 42 | 104 | 39 |
Company Information
Qingdao Yanfei Rigging Co.,Ltd is located in Qingdao, China. For many years supplies a range of industrial products that covers lifting, lashing, slings, rigging, marine, mining, towing, transportation, construction, fishing and security applications... We provide not only high quality goods but also more additional benefits for our clients and partners.
Application
What We Have · China Leading Producing Technology
· Big Production Ability
· Fast Delivery
· Super High Quality
· Competitive Price
· Ten Years' Export Experience
· Excellent Sale and After-sale Service
· OEM Available
Contact
Qingdao Yanfei Rigging Co., Ltd specializes in the field of Chain & Chain Sling, Wire Rope & Wire Rope Sling, Rigging Hardware, Marine Hardware, Lifting Sling & Hoist Equipment, Cargo Control and Transport Products, Tools & Other Products.
We are located in Qingdao, China, which is very convenient and adjacent to Qingdao International Airport and cargo container port.
Our company's reputation has been built on Quality, Safety and Service. In all markets safety is critical, and this starts with a quality product backed by a reliable company. All the products are produced under strict standard of quality control, and constant research and development ensuring that you will get the latest products produced with the most advanced and cost effective technologies.
We put customer first. One of the top priorities is to make sure that our quality management system is a world-class one so that the service we provide is consistent and the best in the market. We are here waiting for you!
