Double Acting High Tonngue 150 Ton Hydraulic RAM

Name: Double Acting High Tonngue 150 Ton Hydraulic RAM
Brand: tool-buy.com
SKU: 814600975
Availability: InStock
Rating: 4.4 (122 reviews)

Price:	US $ 650-1200/Piece
Min Order:	1/Piece
Pay Type:	T/T

Contact Supplier

Taizhou Kashon Power Equipment Co., Ltd.

Showroom Product Company Profile

Prod Model:	CLRG
Color:	Follow Customer(Yellow, Green,Red)
Application:	Lifting, Pushing, Pulling
Working Pressure:	700 Bar
Ship:	International
Coll Height:	196-446mm
Stoke:	50-300mm
Characterstic:	Double Acting ,High Tonnage
OEM Service:	Can Put Customers' Brand
Body Material:	Steel
Operate:	with Manual or Electric Pump
Type:	Hydraulic Jack
Power Source:	Hydraulic
Structure:	Hydraulic RAM
Capacity (',Load):	150 Ton

Product Description

KASHON hydraulic cylinders are available in hundreds of different mechanical or hydraulic cylinders configurations. Whatever the industrial application; lifting, pushing, pulling and available in range of force capacities, stroke lengths or size restrictions. Single or double acting, hollow plunger, or low height, you can be sure that KASHON has the hydraulic cylinder to suit your high force application.
Features:
High tonnage double acting hydraulic cylinders are designed specifically for heavy lifting up to 1,000 tons
Double-acting, for positive retraction
Integral stop ring provides piston blow-out protection
Safety valve in retract side of cylinder helps to prevent damage in case of accidental over-pressurization
Plunger wiper reduces contamination, extending cylinder life
CR-400 coupler and dust cap included on all models
Baked enamel finish and plated pistons provide superior corrosion resistance.
Specifications:

Cylinder Capacity	Stroke	Model Number	Maximum Cylinder Capacity (kN)		Cylinder Effective Area (cm2)		Oil Capacity (cm3)		Coll. Height	Ext. Height	Outside Dia.	Weight
ton	mm		Push	Pull	Push	Pull	Push	Pull	mm	mm	mm	kg
150	50	CLRG-1502	1390	675	198,6	96,5	993	482	196	246	205	39
150	100	CLRG-1504	1390	675	198,6	96,5	1986	965	246	346	205	52
150	150	CLRG-1506	1390	675	198,6	96,5	2978	1447	296	446	205	65
150	200	CLRG-1508	1390	675	198,6	96,5	3971	1930	346	546	205	78
150	250	CLRG-15010	1390	675	198,6	96,5	4964	2412	396	646	205	92
150	300	CLRG-15012	1390	675	198,6	96,5	5957	2895	446	746	205	105

Photos:

Company Information
Kashon Equipment has been in hydraulic tools industry since 2002. mainly export:
Hydraulic cylinder/jacks/rams (5-1500ton), single double acting, hollow plunger; low height, lock nut;
Hydraulic torque wrenches(100-72000Nm);
Hydraulic lifting pumps, manual and electric type;
Hydraulic pullers, manual and hydraulic type;Hydraulic flange spreader, manual and hydraulic type
Hydraulic steel wire rope press machine
Hydraulic accessories(hoses, couplers, oil distributors, etc.)
Over the years we have grown into a diversified market based that now services customers all over the world. We enjoy listening to our customers needs and ideas while working hard to provide the best service and delivering the highest quality of parts.

We believe "service" is our number one customer. We hope our commitment to provide our customers quickly and efficiently with competitive prices will keep you coming back.
