EMT-1632D Battery Powered Hydraulic Pipe Crimping Tool
| Price: |
US $ 600-700/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T |
| Prod Model: |
EMT-1632D |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Model No.: |
EMT-1632D |
| Crimping Capacity: |
Max. Dia. 32mm |
| Applicable For: |
Pex Pipe Mlcp Stainless Steel Pipe Copper Pipe |
| Output: |
6.7t |
| RAM Stroke: |
16mm |
| Battery: |
Li-ion 18V 3ah |
| Charging Time: |
2 Hours |
| Standard Accessories: |
1 Charger 2 Battery 1 Shoulder Strap |
| Package: |
Plastic Carrying Case |
| Weight: |
5.3kgs |
Product Description
EMT-1632D is a Battery Powere Hydraulic Tool, to be used to Crimp Radial Style Pipe Sleeve onto pipe and pipe fitting for the connection job of PEX Pipe, Multi-layer Composite Pipe, Stainless Steel Pipe and Copper Pipe. Now, U B TH SV profile dies are available, special dies also can be ordered for pipe and pipe fittings from different manufacturer if pip, pipe fittings, die samples, drawings and necessary information can be provided
Specification and Feature
1. Output: 6.7T Ram Stroke: 16mm
2. Crimping Dies
| Profile | Size (mm) | Remark |
| B | 16 20 26 32 | For PEX Pipe
and MLCP |
| U | 16 20 25 32 |
| TH | 16 20 26 32 |
| SV | 13 20 25 | For Stainless Steel Pipe |
3. Battery: Li-ion 18V 3Ah Charging Time: 2 Hours
4. Latch Type Head can be easily opened for quick die installation and easy access to pipe
5. Interchangeable dies ensure precise crimping for pipes in different size and construction
6. Pistol Tool Body design for better balance
7. Powerful motor provide sufficient working force
8. High-performance Li-ion battery ensure long working time per charge
9. Quick speed hydraulic system ensure quick dies movement with ram advancement
10. With safety valve, automatically retract ram when complete crimping
11. With manual retract button, die can be returned at any time during operation for necessary adjustment
12. White LED illuminate dark working area and can remain light for 4 seconds after release switch
13. Red LED indicate the working condition of tool and battery
14. Plastic case package for easy carrying and storage
15. Shoulder strap ensure easy handling for overhead working
We, Yuhuan Modern Tools Co., Ltd, a professional tool manufacturer, was established in 2002, officially start our business with the hydraulic crimping tool, then with the development of our factory and also in order to keep pace with the demand of our customers, we gain our own brand "BAISHITE" in our local market and extend our product range step by step to: Hydraulic cutting tool, busbar punching, bending, cutting tool, puncher, compatible hydraulic pump, hydraulic jack, Ratchet Cable cutter, mechanical crimping pliers, long-Arm cutters, all these tools can be widely used in electric construction and distribution project for cutting, crimping, lifting, to make the job easy, quick and safe.
In order to expand our production and make our company more competitive, we bid for the land, built and moved to our current factory in 2007 (Factory Address: Bingang Industrial Area Shamen Yuhuan Zhejiang China 317607), the new machines (CNC Machine, Linear Cutting Machine, Grinding Machine, Punching Machine, Heat Treatment Machine etc) are also purchase accordingly. Now, we produce tools and provide service for customers from Germany, Russia, Ukraine, UAS, Japan, Korea, Taiwan, Thailand, Singapore, Hongkong etc., relative Certificate (ISO CE) are also applied and gained. With the feedback from our customers, we also improve tools and change tools design, to make our tools more qualified and meet the changing demand of the target market. Now, we officially add the battery powered tools (crimping, cutting, punching) in our products range, to aim to the high-level market.
Considering the potential of Plumbing tools in Australia, Brazil, Germany, Russia and also our domestic market, based on our current tools, we also start to design and produce crimping tools, pressing tool, expanding tools for PEX pipe, Multi-layer Composite Pipe, Stainless Steel Pipe and Copper Pipe in hydraulic, Mechanical and battery powered style. Thanks to the contribution of our workers and the support our customers, these brand new pluming tools also get positive market feedback.
Keep improving current tools, Never Stop designing New tools for new application, we are confident that we'll make our factory more competitive with more qualified tools and better service
