| Prod Model: |
XGQ41F-16P/R |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size: |
Dn15-Dn200 |
| Material: |
Stainless Steel |
| Connection Form: |
Flange |
| Channel: |
Straight Through Type |
| Structure: |
Floating Ball Valve |
| Type: |
Floating Ball Valve |
| Application: |
Water Industrial Usage |
| Nominal Pressure: |
Pn16, JIS10k, ANSI 150lb |
Product Description
This type of tank bottom valve has obtained the patent for utility model which is innovative designed for special equipment with insulation jacket.
Inclined stem design, enlarge the angle between actuator and bottom of storage tank, so that the actuator can be in good protection. Use ISO5211 actuator platform design, without connection bracket make the actuator drive easily assembled.
Be widely used in reactors, vessels and storage tanks, for Biotechnology, Pharmaceutical, Food & Beverage, Chemical and Cosmetics Processing.
FAQQ1: We are interested in your products?
A1: In order to recommend you suitable products, please provide detail information, like size, material, pressure, temp, company info etc.Q2: Is the requirement for MOQ?
A2: There are hundreds of products we sell, it depends on your order.Q3: How about the warranty?
A3: The warranty time is 12 months after leaving our factory when on board.Q4: How about delivery time?
A4: It can be 5-40 days, but depends on if valve in stockQ5: Can you manufacture different standards valves according to customer requirements?
A5: Yes. We do, actually we have many experienceIf you want to know more about our products, please contact freely. We will patiently answer your all questions.
