| Prod Model: |
DIN1480 |
| Finish: |
Color-Zinc Plated |
| Function: |
All |
| Grade: |
Common |
| M.O.Q: |
100 Tons in One Month |
| Other Material: |
Alloy Steel, Stainless Steel |
| Standard: |
Us Type |
| Surface: |
Self-Color, Hot Dipped Galvanized, Electroplating, |
| Ports: |
Port of Qingdao,Port of Shanghai or Other |
| Working Load: |
500 to 75000 Lbs |
| Process: |
Drop Forged |
| Material: |
Steel |
Product Description
Forged U.S Type Turnbuckles With Jaw And Jaw
. Material:carbon steel
2. Surface: self color,galv and others
3. Proof load is 2.5 times of WLL and breaking strength is 5 times of WLL.
| Forged U.S Type Turnbuckles With Jaw And Jaw |
| SIZE | WLL | WEIGHT |
| NI. | LBS | LBS |
| 1/4"×4" | 500 | 0.36 |
| 5/16"×4-1/2" | 800 | 0.52 |
| 3/8"×6" | 1200 | 0.81 |
| 1/2"×6" | 2200 | 1.56 |
| 1/2"×9 | 2200 | 1.74 |
| 1/2"×12" | 2200 | 2.4 |
| 5/8"×6" | 3500 | 2.72 |
| 5/8"×9" | 3500 | 3.43 |
| 5/8"×12" | 3500 | 3.91 |
| 3/4"×6" | 5200 | 4.11 |
| 3/4"×9" | 5200 | 5.46 |
| 3/4"×12" | 5200 | 6.43 |
| 3/4"×18" | 5200 | 8.07 |
| 7/8"×12" | 7200 | 8.17 |
| 7/8"×18" | 7200 | 10.78 |
| 1"×6" | 10000 | 10.18 |
| 1"×12" | 10000 | 12.52 |
| 1"×18" | 10000 | 15.14 |
| 1"×24" | 10000 | 18.08 |
| 1-1/4"×12" | 15200 | 20.59 |
| 1-1/4"×18 | 15200 | 24.68 |
| 1-1/4"×24" | 15200 | 28.2 |
| 1-1/2"×12" | 21400 | 30.69 |
| 1-1/2"×18 | 21400 | 36.75 |
| 1-1/2"×24" | 21400 | 40.67 |
| 1-3/4"×18" | 28000 | 54 |
| 1-3/4"×24" | 28000 | 63.36 |
| 2"×24" | 37000 | 94.25 |
| 2-1/2"×24" | 60000 | 165 |
| 2-3/4"×24" | 75000 | 198 |
We are the MANUFACTURER of high quality rigging with competitive price.Such as eye bolts and eye nuts, turnbuckle shackles,wire rope clips.etc.
We understand from your information posted on company websites.that you are in themarket for rigging. We would like to take this opportunity to introduce our company and products.
Because of Factory , we can support to design by customer .
Our main products contain carbon steel rigging hardware, stainless steel fittings and concrete lifting hardwares and OEM fabrication and stamping. The quality concept take first priority at Xinlong Hengda Metal, and professional service with high price competitiveness offer you best satisfaction. In addition, with the innovated CNC-controlled forging production lines and rich professional experience, Xinlong Hengda Metal also offer service for customers' specific needs.
Benefit from Xinlong Hengda Metal:
- High Quality Reliability
- High Availability on Extensive Range of Products
- High Price Competitiveness
- Specific Solutions
To our partners, we keep to the philosophy of sincerity, innovation, cooperation and mutual benefit. "Only customer succeed, then we success" We wish to establish cooperation with new partners and friends at home and abroad for mutual growth and mutual prosperity.
As a professional manufacturer of lifting and connecting hardware, Xinlong Hengda Metal has been operating successfully and expanding the business range rapidly over last decade. International customers cover 68 cities in 27 countries and still increasing. Xinlong Hengda Metal provides an extensive range of quality products to the customers from industry to industry, such as mechanical engineering, agricultural machines, auto industry, construction industry, shipyards, out-door decoration, screw and hardware industry and etc.
