Glossy Oil UV Coating Machine for CD DVD Disc

Prod Model:	RC-GO50
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Style:	Refresh Color
Max Paper Size:	120mm
Color Print Speed:	15 Seconds
Place Of Origin:	Guangdong, China
Gross Power:	450W
Use For:	Costing Oil on CD/DVD
Dimensions(L*W*H):	500*400*220mm
Authorised:	SGS
Certificate:	ISO
Type:	Roll Coater
Driven Type:	Electric
Automatic Grade:	Automatic
Packaging Material:	Metal
Packaging Type:	Cans
Application:	CD DVD

Product Description

1.CD/DVD high glossy machine
2. make disk surface refresh
3.can print on any kinds of CDs

Disc working width	140mm
Rated voltage	220V
Frequency	50HZ-60HZ
Power	450W
Machine size	500*400*220mm (length*  width*   height)
Carton size	65*50*31cm (length*  width*   height)
Coating speed	2.5m/min, 15 seconds/piece disc
Glossy oil consumption	5-10ml/square
UV lamp	lifetime about1000 hours

1. Usage and function:
This machine is designed especially for post-processing of disc print output.
After you print any logo or patterns on the Printable CD/DVD, you can use this machine to coat gloss oil on the discs. It will protect disc printing perfectly.

Machine / Coating advantages:
(1)Waterproof completely
(2)stain resistance
(3)fade resistance
(4)convenient using
(5)energy conservation
(6)Low cost

2. Specification:
(1)Disc working width: 140mm
(2)Rated voltage: 220V
(3)Frequency: 50HZ-60HZ
(4)Power: 450W
(5)Machine size: 500*400*220mm (length* width* height)
(6) Carton size: 65*50*31cm (length* width* height)
(7)Machine working temperature:
(8)Coating speed: 2.5m/min, 15 seconds/piece disc
(9)Glossy oil consumption: 5-10ml/square,


3. Installation procedures (how to use):
(1) Take out machine and put it on the flat table. There is 8 machine angle (black color) and screws, install them into every angle (small hole) at the bottom of machine and disc tray seperately.
(2)Pour glossy oil into Liquid storage tank (liquid depth can not be more than 1.5cm). And put tank under rubber roller(red color), then put Pipette into tank.
(3) Plug in (connected machine with power line and socket). Open three switch (right side is main switch, middle is UV lamp switch, left side is circulated liquid switch), then machine stars working. UV lamp needs warming, let machine tick over around 3minutes in advance. After that, you can start coating CD/DVD after oil poured over the entire rubber roller.
(4)For 1st time using, if you still can not find glossy oil on the rubber roller after machine opening 3-5minutes, it means there is some air in the circulated pump (the exit of liquid) so that oil can not pour out. At this time, you can use syringe to deflate the air outwards from the exit of pipette.
(5) Put one disc on the tray(words upward), and push disc into the bottom of rubber roller slowly, the machine will coat automatically by itself, the disc will be sent out from the back of the machine once finished
(6) If you feel coated oil is too thin or too thick, you can use hexagon wrench to adjust the gap of two rubber roller. Firstly open the cover which is above rollers, you can see clearly there are 2 small aluminum on both side in the front of roller, and there are 2 small holes. Pls put hexagon wrench into the hole, make it rotated clockwise if you need coated oil thin, the gap between rollers will be narrow. If you need coated oil thick, you can make it rotated counter clockwise, the gap will be wider.
(7)If not to use the machine for long time, you'd better clear rubber rollers before you store it.
