| Prod Model: |
WSVDB-H2 |
| Usage: |
Drilling |
| Kind: |
Diamond Drill |
| Manufacturing Arts: |
Vacuum Sintered |
| Machines: |
Stationary Drill, Cordless Drill, Power Drill |
| Application: |
Dry Drill All Tiles, Porcealins, etc |
| Optimum Rpm: |
Over 1, 500 |
| Feature: |
Self Cooling, Self Sharpening |
| Speed: |
20s/Hole |
| Life: |
30holes on Red Granite, Dry Drill |
Product Description
1. Vacuum brazed dry drill bits can be used in dry drilling of granites, marble, hard tiles, hard porcelain, etc.
2. It will perform much better if used in wet conditions; the life will be times more than the electroplated drill bits which can't be used in dry drilling. Drilling speed is fantastic fast.
3. Could be used wet or dry with cooling slots design for easier core removal when stuck.
4. Drill bits in 6mm, 8mm are with top grade diamonds.
5. Diamond length:8-10mm
6. Self-cooling, self-sharpening(from 6mm-14mm)
7. Diamond grit: 40#
Our dry drill bits are widely accepted among many European countries, our dry drill bits are your best choice.
| Diameter(mm) | Segment Height(mm) | Overall length(mm) | Shank |
| 6 | 8-10 | 35/50/60/65 | Hexangular, Round |
| 8 | 8-10 | 35/50/60/65 | Hexangular, Round |
| 10 | 8-10 | 35/50/60/65 | Hexangular, Round |
| 12 | 8-10 | 35/50/60/65 | Hexangular, Round |
| 14 | 8-10 | 35/50/60/65 | Hexangular, Round |
| 16 | 8-10 | 35/50/60/65 | Hexangular, Round |
| 18 | 8-10 | 35/50/60/65 | Hexangular, Round |
| 20 | 8-10 | 35/50/60/65 | Hexangular, Round |
| 22 | 8-10 | 35/50/60/65 | Hexangular, Round |
| 25 | 8-10 | 35/50/60/65 | Hexangular, Round |
| 30 | 8-10 | 35/50/60/65 | Hexangular, Round |
| 32 | 8-10 | 35/50/60/65 | Hexangular, Round |
| 35 | 8-10 | 35/50/60/65 | Hexangular, Round |
| 38 | 8-10 | 35/50/60/65 | Hexangular, Round |
| 45 | 8-10 | 35/50/60/65 | Hexangular, Round |
| 50 | 8-10 | 35/50/60/65 | Hexangular, Round |
| 55 | 8-10 | 35/50/60/65 | Hexangular, Round |
| 60 | 8-10 | 35/50/60/65 | Hexangular, Round |
| 65 | 8-10 | 35/50/60/65 | Hexangular, Round |
| 70 | 8-10 | 35/50/60/65 | Hexangular, Round |
| 75 | 8-10 | 35/50/60/65 | Hexangular, Round |
| 90 | 8-10 | 35/50/60/65 | Hexangular, Round |
| 100 | 8-10 | 35/50/60/65 | Hexangular, Round |
| 120 | 8-10 | 35/50/60/65 | Hexangular, Round |
Wanshin Diamond Tool Co., Ltd is a professional manufacturer and exporter of various types of diamond tools. Our company is located in the city of Nan' An_the biggest stone base in China.
With over 20 years experience in the researching and manufacturing of stone tools, over 5 years in the vacuum brazed diamond tools, our products are widely accepted by many customers all over the world. Our main products include the following series:
1. Cutting tools: Diamond saw blade, diamond segments, diamond gang saw, diamond wire saws, diamond drill bits, construction cutting saw blades, etc;
2. Vacuum Brazed Diamond Tools: Such as vacuum brazed drill bits for tiles, porcelain, ceramics;
3. Stone Engraving Tools
4. Polishing&Grinding Tools: Such as diamond polishing pads, diamond cup wheels, metal grinding discs, resin grinding discs, concrete floor polishing pads, etc;
5. Electroplated Diamond Tools: Such as wet drill bits, CBN plated diamond wheels, grinding pins, etc
All of our products are inspected under a strict quality control system before it goes to customers' Hands.
Now our products are exported USA, UK, Germany, Australia, Iran, Peru, Mexico, Brazil, South Africa, Cyprus, Egypt, Poland, etc.
Our principle is helping you get the best solutions for your limitations in the processing of stones and many other materials. We sincerely welcome to you to join us, we can supply you the constantly good quality products, the best after sale service.
