Home Toolbuy Products High Percision Taper Roller Bearing 32205 / Machine Tool Bearing 32205

High Percision Taper Roller Bearing 32205 / Machine Tool Bearing 32205

High Percision Taper Roller Bearing 32205 / Machine Tool Bearing 32205
Price: US $ 0.01/Piece
Min Order: 1000/Piece
Pay Type: L/C,T/T,Western Union,Paypal
Contact Supplier
Guangzhou Wafangdian Bearing Co., Ltd.
Showroom Product Company Profile
Prod Model: 32205
Sample: Available
Service: OEM
Customer Brand: Acceptable
Logo: Customize
MOQ: 1000sets
Fob Port: Qingdao,China
Stock: Yes
Delivery Date: 7 Days
Customize Order: Acceptable
Size: Standard Size
Type: Wheel Hub Bearing
Material: Chrome Steel
Tolerance: P0
Certification: TUV
Clearance: C0
ABS: Without ABS
Brand: Lyaz/OEM
Application: All

Product Description

Quick Details
Structure:
Taper
Type:
Roller
Brand Name:
OEM or LYAZ
Bore Size:
15 - 160 mm
Outside Diameter:
60 - 250 mm
Model Number:
all types
Precision Rating:
P0 P6 P5 P4 P2
Seals Type:
Open
Number of Row:
Single Row
Place of Origin:
Guangzhou,China (Mainland)
Material:
Chrome Steel, GCR15, Carbon Steel, Stainless Steel
Certificate:
ISO 9001:2008 ISO/TS 16949
Feature:
Long Life, high Speed, Low Noise, Low Libration, High Pressure
Service:
OEM, Free Sample, Fast Delivery
Quality:
Top, Best, Good, Fine
HARDNESS:
60--65HRC
Stock:
Large
Delivery time:
5-30DAYS, Fast
Main market:
Europe, America, Asia, etc
Application:
Automotive, Machinery, Mining, etc
Packaging & Delivery
Packaging Details:1)plastic tube+Kraft Paper +carton pallet
2)1piece//pp bag+color carton box+master carton +pallet
3)As customers' requirements
Delivery Detail:5-30 days after placing the order or according to qty

Series models specification:

Bearing modelsDimensionsLimited speed ratingLoad ratingsAppro weight(kg)
ID(mm)OD(mm)Thickness
(mm)		GreaseOilDynamic(N)Static(N)
30303174715.2592001200027400245000.129
30304205216.2583001100031500332000.165
30305256218.256900870049200481000.265
30306307220.755900750061300626000.387
30307358022.755200660078400820000.518
30308409025.2546005800952001075000.746
303094510027.25410052001140001297000.988
303105011029.25380048001223001545001.28
303115512031.5340043001587001847001.63
303126013033.5320040001776002070002.003
303136514036290037002037002394002.43
303147015038270035002281002696003.006
303157516040260032002648003187003.57
303168017042.5240030002970003524004.27
303178518044.5230029003194003881004.958
303189019046.5210027003583004408005.79
303199520049.5200026003685004777006.782
3032010021551.5170024003500003430008.22
3032110522553.5150019004320005620009.38
3032211024054.51400180047200061200011
3032412026059.51500700043500041000014.2
3032613028063.751400180056300068400017.4
3032814030067.7513001700626C0076100027.2
3033015032072970140061600075000025.5



Packaging & Delivery
Packaging Details:1. craft paper rolled/plastic bucket +carton +pallet
2.individually packing +carton +pallet
3.As customer's request
tapered roller bearing size chart 30202 30203 30204 30205 30206
Delivery Detail:Shipped in 15 days after payment


Tapered roller bearing type belongs to the separation bearing, have tapered roller bearing inner and outer race.According to these bearings on the column number of the roller is divided into single row, double row and four row circular cone roller bearings these different structure. Single row circular cone roller bearings can bear radial load and the single direction axial load. When bearing radial load, axial force component, would create a so when need another affordable bearing axial force in the opposite direction to balance




Wafang Dian Bearing Advantage

1. Material Advantage
All the material for Wafang Dian bearing are from the best suppliers in China.

2. Processing Advantage
we can guarantee the time spent and quality of every processing. We can do three times tempering to stabilize the dimensions of the bearings, which is quite different from other bearings manufacturers.

3. Quality control advantage
All the bearing parts are 100% strictly inspected before and during production including Metallurgical testing, crack detection, roundness, hardness, roughness and g++eometric dimensions.

4. All of bearings meet the ISO international standard.

5. Appearance Technology Advantage
we can provide light chamfer, black chamfer, black chamfer of the rollers. The bearings are produced all according to customer's requirements.

6. Service Advantage
Your satisfaction is our biggest goal. From quotation to the final packing and transport, we provide the quickest and most satisfactory services to every customer.


We participate Canton Fair,Shanghai Auto Mechanika Fair,Professional Auto Parts Fair annually.

Welcome Inquiry and order !
Thank you!

Guangzhou Wafangdian Bearing Co., Ltd. is a professional bearing company, belongs to Liaoning Wafang Dian Aoli Yuan Bearing Manufacturing Co. Ltd, , locates in Wafangdian north Gongji street, covers an area of more than 50000 square meters, over 300 staffs work in the factory. The annual production is more than 10 million sets of various bearings.

We have more than 30 years bearing manufacturing experience, execute strict and responsible quality control. Our products are: Deep groove ball bearing, tapered roller bearing, cylindrical roller bearing, spherical roller bearing, thrust ball bearing, needle bearing, self-aligning ball bearing, angular contact ball bearing, pillow block bearing, wheel hub bearing, clutch bearing, composite bearing and all kinds of non-standard bearings. Our bearings are low noise, long working life, high precision, high speed, heavy duty, good temperature resistance, widely used in automobiles, machine tools, mining, oil field, paper making, cement plant, power plant, steel mill, construction machinery and many other industries.

We are strong in research and development. We can design and produce bearings with drawings or samples to meet customers' specific needs. OEM services are also provided with customers' authorization. Small orders are accepted, free samples are available. We guarantee high quality, competitive prices, on-time delivery, fast response. Welcome all distinguished guests at home and abroad to contact us for business, looking forward to working with you hand in hand, create more brilliant future together!
