High Pressure 4 Inch DIN F4 Ductile Cast Iron Ggg50 Resilient Seated Nrs Sluice Gate Valve
| Price: |
Negotiable/Ton |
| Min Order: |
20/Ton |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
| Body: |
Ductile Iron Ggg40/50 or Cast Irongg25 |
| Color: |
Blue, Red or as Per Customer's Requirements. |
| Coating: |
Internal and External with Fusion Bonded Epoxy Coa |
| Flange Drilling: |
According to DIN2501, BS4504 and ANSI B16.1 Pn10,P |
| Certificate: |
ISO9001, BV, Wras, SGS,etc |
| Material: |
Cast Iron |
| Connection Form: |
Flange |
| Application: |
Household Usage |
| Thread Position Of Valve Rod: |
Outside/Inside Gate Valve |
Product Description
high pressure 4 inch DIN F4 ductile cast iron ggg50 resilient seated NRS sluice gate valve
1 | Standard | DIN 3352-F4 ,DIN 3352-F5, BS5163, AWWA C509 ,AWWA C515 Flange drilling is according to DIN2501, BS4504 and ANSI B16.1 PN10,PN16,PN25 |
2 | Type | Flanged End , Socked End ,Mechanical Joint, non rising stem / rising stem |
3 | Material | Ductile iron GGG40/50 or Cast IronGG25 |
Ductile iron GGG40/50+EPDM/NBR or metal seated |
stainless steel 2Cr13 , SS304,SS316 |
Carbon Steel with zinc plated or SS304,316 |
4 | Port Size | DN40-DN600 |
5 | Pressure | PN10/PN16/PN25 |
6 | Media | Water, oil, gas, etc |
7 | Coating | Internal and external with fusion bonded epoxy coating min250μm |
8 | Packaging | Plywood case |
