High Quality Cemented Carbide Inserts-Tungsten Carbide Blade-Tungsten Carbide Knife

Prod Model:	YM6
Condition:	New
T.R.S MP:	2400
Purity:	>99.95%
Shape:	Rectangular
Product Type:	Alloyed
Carbon Content:	Customized
PCD:	90.5
Et:	by Customers′requirement
Hole:	by Customers′requirement

Product Description

We are manufacturer specialize in producing tungsten carbide products and carbide tools. We could supply good quanlity of indexable inserts, and all products are sintered with Hip process.

Grades,properties and applications of cemented carbide cutting tools.

Grade	Density g/cm3	Hardness HRA	T.R.S MP  a	Performance&application recomended	ISO Code
YM3A	15.1	94	1700	Suitable for finishing of cast iron and nonferrous metal.	K01~K05
YM3X	15.2	92	1800
YM6A	14.85	92.5	2200	Suitable for the semi-finishing cast iron and nonferrous metals and also for the machining of manganese steel and hardened steel.	K10
YM6X	14.90	91.5	2300
YM6	14.95	90.05	2400	Suitable for the roughing of cast iron and light alloys and also for the milling of cast iron and low-alloy steel.	K15
YM8	14.7	89.8	2800		K20
YM2T	14.3	92.0	2500	Suitable for finishing and semi-finishing of stainless steel and conventional alloy steel.	M10
YW1	13.1	91.6	1600
YW2	13	90.6	1800	The grade can be used for the semi-finishing of stainless steel and low-alloy steel and it is mainly used for the machining of railway wheel hubs.	M20
YT15	11.4	91.5	1600	Suitable for the finishing and semi-finishing for steel and cast steel with a moderate feed rate and rather high cutting speed.	P10
YT14	11.6	90.8	1700	Suitable for the finishing and semi-finishing of steel and cast steel.	P20
YT15	12.9	90.5	2200	Suitable for the heavy cutting of steel and cast sttel with a big feed rate at medium and low speed under unfavorable working conditions.	P30
Other grades and size can be offered as per customers'requirements

Kingdon is a professional Chinese supplier of tungsten carbide products, We have been doing manufacturing more than 35 years. Such as carbide saw tips, carbide cutting tips and inserts, carbide rods, carbide blanks, materials for dies and moulds (drawing dies, cold heading and punching dies), indexable inserts, carbide woodworking cutter, carbide mining tools, carbide strips and plates, and etc.
Also, we can offer non-standard carbide products such as disc cutters, rollers, rings, bars, hammer drill tips, balls, toothpick tips, forming cutters, mould cutters, nozzles, plates, lining boards, trundling scissors and other special wear parts for the different applications in the modern industry.

Special dimensions and shapes according to customers' drawings and specifications.
