| Prod Model: |
XA-WM001 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Zinc Coated: |
3G/Mm-15g/Mm |
| Width: |
0.5m-1.5m |
| Export Markts: |
Global |
| Length: |
12-28m/Roll |
| Wire Diameter: |
0.43mm-1.35mm |
| Certificate: |
ISO9001 |
| Aperture: |
1/2'' 1/3'' 1/4'' 2/3'' 3/4'' |
| Type: |
Welded Mesh |
| Certification: |
ISO9001 |
| Mesh Size: |
2 Inch |
| Application: |
Decorative Mesh |
| Surface Treatment: |
Galvanized |
| Material: |
Galvanized Iron Wire |
| Hole Shape: |
Square |
| Condition: |
New |
| Color: |
Silver |
| Weave Technique: |
Welded |
Product Description
Welded wire mesh
Concrete reinforcement wire mesh(factory)
Reinforcement wire mesh
Cement wire mesh
Wire 5-16mm
Mesh 10*10cm, 15*15cm, 20*20cm
Concrete reinforcing wire mesh(factory)
1. Technical Info:
Wire diameter: For welded steel bar panel ranges from 5mm to 16mm.
Welded bar panel opening: 75mm to 300mm.
Panel length: 100cm to 1200cm.
Panel width: 100cm to 230cm
2. Applications:
Used in construction reinforcement, the ground for the tunnels, bridges, highway, airport and wharf, also in construction of wall body, making of floors, ceilings, wall body, concrete road, bridge surface, airport, tunnel lining, concrete piping, mesh rack, international partritioning, shelving etc.
| No. | Types | Wire Spacing | Wire Diameter | Sheet
Dimensions/m | Weight per
sheet kg/pc |
| Main mm | Cross mm | Main mm | Cross mm |
| 1 | A98 | 200 | 200 | 5 | 5 | 2.15 X 5.00 | 16.7 |
| 2 | A142 | 200 | 200 | 6 | 6 | 24.1 |
| 3 | A193 | 200 | 200 | 7 | 7 | 32.8 |
| 4 | A252 | 200 | 200 | 8 | 8 | 43.0 |
| 5 | A393 | 200 | 200 | 10 | 10 | 67.1 |
| 6 | B503 | 100 | 200 | 8 | 8 | 64.7 |
| 7 | B785 | 100 | 200 | 10 | 8 | 89.1 |
| 8 | A98* | 200 | 200 | 5 | 5 | 1.80 X 3.00 | 8.3 |
| 9 | A142* | 200 | 200 | 6 | 6 | 12.0 |
| 10 | A252* | 200 | 200 | 8 | 8 | 1.75 X 3.00 | 21.0 |
| 11 | A393* | 200 | 200 | 10 | 10 | 32.9 |
| 12 | Q92 | 150 | 150 | 4.2 | 4.2 | 2.15 X 5.00 | 15.9 |
| 13 | Q131 | 150 | 150 | 5 | 5 | 22.5 |
| 14 | Q188 | 150 | 150 | 6 | 6 | 32.4 |
| 15 | Q257 | 150 | 150 | 7/5(? | 7 | 39.7 |
| 16 | R92 | 150 | 250 | 4.2 | 4.2 | 12.8 |
| STEEL | Cold reduced, high tensile, deformed, according to BS 4482 |
