| Prod Model: |
diamond blade |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Diameter(Mm): |
105 - 600 |
| Segement Thickness(Mm): |
2.0 - 4.5 |
| Segment Hight(Mm): |
10 |
| Inner Hole(Mm): |
20/22.23/25.4 |
| Segment No.(PCS): |
8 - 42 |
| Advantage: |
Quality and Price |
| Slot Type: |
Key Slot |
| Welding Way: |
Laser Welding |
| Usage Way: |
Dry & Wet Cutting |
| Delivery Detail: |
7 - 15 Days |
| Usage: |
Stone Cutting |
| Manufacturing Arts: |
Sinter |
| Kind: |
Diamond Saw Blade |
| Saw Blade External Diameter: |
105-600mm |
Product Description
150mm Laser Welding Saw Blade for Granite
1. Adopt laser welding techniques which bring fast and safety cutting...
2. Used for dry cut or wet cut
3. It can be widely applied.
Advantage:
Easy to operation
Sharp and fast cutting
Suitable for dry and wet cutting
Feature
1. Cutting depth: 30mm
2. Surface Tolerance: Less than 0.10mm
3. K slot provide the better cooling performance
4. Super fast cutting speed
When you place the order, please the more details about the concrete saw blade you want:
Diameter
Inner hole
Segment size (if need special request )
Thank you in advance!
|
Diameter |
Segement Thickness |
Segment Height |
Inner hole |
Segment No. |
|
mm |
mm |
mm |
mm |
pcs |
|
105 |
2.0 |
10 |
20 |
8 |
|
115 |
2.0 |
10 |
22.23 |
9 |
|
125 |
2.0 |
10 |
22.23 |
10 |
|
150 |
2.4 |
10 |
22.23 |
11 |
|
180 |
2.4 |
10 |
22.23 |
14 |
|
200 |
2.4 |
10 |
22.23 |
16 |
|
230 |
2.6 |
10 |
22.23 |
18 |
|
250 |
2.8 |
10 |
22.23 |
20 |
|
300 |
3.2 |
10 |
25.4 |
21 |
|
350 |
3.2 |
10 |
25.4 |
24 |
|
400 |
3.6 |
10 |
25.4 |
28 |
|
450 |
3.8 |
10 |
25.4 |
32 |
|
500 |
4.0 |
10 |
25.4 |
36 |
|
600 |
4.5 |
10 |
25.4 |
42 |
QUANZHOU SUNNY SUPERHARD TOOLS Co., Ltd is a professional and Dynamic Diamond Tools manufacturer, established in 1993, Located in Quanzhou, Fujian province, China, factory covering 15000 square meters. Our technical department is composed of experienced professors and engineers. We devote ourselves to researching and manufacturing cutting and processing Diamond tools for nature stone and building materials. Our tools are exported to more than 60 countries, including America, Brazil, Italy, Russia, Ukraine, India, Egypt, South Africa etc.
Main Products:
Cutting Tools (Saw blade, Segment, Wire saw etc)
Grinding&Polishing Tools (Calibration Rollers, Fickerts, Frankfurt, Cup wheel, Profilling wheel, Polishing pad, brush etc)
Drilling Tools (Finger Bit, Core drill etc)
The Philosophy of Sunny is "Superior product and service derived from standard and efficWe have a high efficiency team, each department strictly comply with company regulations.
From receiving your enquiry, put order in production and Dispatch to after-sales service, Ient management. "
In order to provide customer most suitable tools, we keep researching and analysing nature stone and engineering material. We cooperate with stone factory to test tools, and keep close contact with our customers by visit or communication to get knowledge of market demand.
We Response All Your Request efficiently To Save Your Time And Provide Your Utmost Convenience.
The deep understanding for customer's demand and strict quality control help us developing quickly, we wish to get your collaboration to achieve our objectives together!
Our aim is to provide our clients stable and consistant quality with competitive price.
Advantages enable clients benefits from our tools.
1. Experienced bond system
2. Advanced equipment and high grade raw material
3. Strictly production procedures control and quality inspection.
4. Customer's active feedback and support help us developing fast.
