| Prod Model: |
WSTDB-M14 |
| Usage: |
Drilling |
| Manufacturing Arts: |
Sinter |
| Kind: |
Diamond Drill |
| Application: |
Dry Drilling Granite, Engineer Stones, etc |
| Segment: |
Turbo Design Shape Segment |
| Protection Teeth: |
Vacuum Brazed Diamond Stripes on The Steel Wall |
| Working Condition: |
Specially Good for Dry Use |
| Features: |
Dry Use, Fast Speed, Long Life |
| Thread Available: |
M14, 5/8''-11, etc |
| Diamond Stripes: |
10*35mm |
Product Description
Diamond Drill Bit with Protection Diamond stripes for dry drilling granite, dry use
This diamond drill bit is for dry drilling of granite and many other hard stones, the turbo design segments allows the dry drilling, and the vacuum brazed diamond stripes give protection to the steel, which will increase the drilling speed and improving the working life. There are also vacuum brazed diamond stripes inside the stee core.
Regular sizes: 30mm, 32mm, 35mm, 51mm
Segment height: 10mm
Overall length: 105mm
Custom sizes are availlabe
