Prod Model: |
6304 |
Brand Name: |
Lyaz or OEM |
Packaging Details: |
Neutral Packing or Our Own Brand Packing |
Precision Rating: |
Po,P6,P5,P4,P2,P3,P1 |
MOQ: |
1000sets |
Guarantee: |
One Year |
Place Of Origin: |
Guangzhou,China |
Sample Available: |
Yes |
Customer Logo: |
Acceptable |
Customer Brand: |
Acceptable |
Noise Rating: |
Z1 Z2 Z3 Z4 |
Rolling Body: |
Ball Bearings |
The Number Of Rows: |
Single |
Outer Dimension: |
Small (',28-55mm) |
Material: |
Bearing Steel |
Load Direction: |
Thrust Bearing |
Separated: |
Unseparated |
Product Description
Quick Details
Structure: | Deep Groove | Type: | Ball | Brand Name: | International Brands |
Model Number: | 6328 | Precision Rating: | P0,P6,P5,P4,P2 | Seals Type: | OPEN,Z,ZZ,RS,2RS, N,NR, ZNR |
Number of Row: | Single Row | Place of Origin: | Sweden | Bearing Name: | deep groove ball bearing |
Inner Size:: | 140 | Outer Size:: | 300 | Thickness:: | 62 |
Material:: | Chrome Steel | Row Number:: | single row |
Packaging & Delivery
Packaging Details: | Original Package+big paper box+pallet |
Delivery Detail: | 1~2 days, according to quantity |
Specifications
deep groove ball bearing
International Brands
Reasonable Price
Long Using Life
Quick reply Fast
140*300*62 mm deep groove ball bearing 6328 RZ ZZ 2Z RS 2RS 2RSR NR ZNR DDU ZR 2RS1 2RZ
Bearing 6328 is Deep Groove Ball Bearing, with inner ring, outer ring and balls.
Bearing 6328 is a very common deep groove ball bearing. This bearing has many seal type, include OPEN, Z, ZZ, RS, 2RS, NR, ZNR. Here are the diameter of bearing 6328.
Name | Deep Groove Ball Bearing |
Model NO. | 6328 |
Seal Type: | Open RZ ZZ 2Z RS 2RS 2RSR NR ZNR DDU ZR 2RS1 2RZ and others |
Inner Size: | 140 mm |
Outer Siez: | 300 mm |
Thickness: | 62 mm |
Clearance: | C0,C2,C3,C4,CM |
Vibrication: | Z1, Z2, Z3 |
Package: | Original Single box package + Big Paper Box + Pallet |
Material | stainless steel, chrome steel, carbon steel |
Bearing 6328- pictures for your reference:
Type | Dimensions (mm) | Basic Load Rating (N) | Limiting Speed (rpm) | Weight (Kg) |
d | D | B | r (min) | Dynamic | Static | Grease | Oil |
625 | 5 | 16 | 5 | 0.3 | 1460 | 598 | 35000 | 42000 | 0.0048 |
626 | 6 | 19 | 6 | 0.3 | 2800 | 1058 | 32000 | 38000 | 0.0081 |
627 | 7 | 22 | 7 | 0.3 | 3310 | 1350 | 30000 | 35000 | 0.013 |
628 | 8 | 24 | 8 | 0.3 | 3330 | 1410 | 29000 | 34000 | 0.017 |
629 | 9 | 26 | 8 | 0.3 | 4550 | 1950 | 25000 | 31000 | 0.02 |
6200 | 10 | 30 | 9 | 0.6 | 5110 | 2390 | 23000 | 28000 | 0.032 |
6201 | 12 | 32 | 10 | 0.6 | 6800 | 3050 | 20000 | 24000 | 0.037 |
6202 | 15 | 35 | 11 | 0.6 | 7600 | 3680 | 17000 | 21000 | 0.045 |
6203 | 17 | 40 | 12 | 0.6 | 9580 | 4800 | 16000 | 19000 | 0.066 |
6204 | 20 | 47 | 14 | 1 | 12830 | 6650 | 14000 | 16000 | 0.106 |
6205 | 25 | 52 | 15 | 1 | 14020 | 7930 | 11000 | 13000 | 0.128 |
6206 | 30 | 62 | 16 | 1 | 19470 | 11430 | 9000 | 11000 | 0.199 |
6207 | 35 | 72 | 17 | 1.1 | 25700 | 15220 | 7800 | 9000 | 0.288 |
6208 | 40 | 80 | 18 | 1.1 | 29520 | 18140 | 6700 | 8000 | 0.366 |
6209 | 45 | 85 | 19 | 1.1 | 31660 | 20730 | 6800 | 7500 | 0.398 |
6210 | 50 | 90 | 20 | 1.1 | 35060 | 23220 | 6100 | 6300 | 0.454 |
6211 | 55 | 100 | 21 | 1.5 | 43500 | 29200 | 6400 | 7600 | 0.602 |
6212 | 60 | 110 | 22 | 1.5 | 52500 | 36000 | 6000 | 7000 | 0.789 |
Wafang Dian Bearing Advantage
1. Material Advantage
All the material for Wafang Dian bearing are from the best suppliers in China.
2. Processing Advantage
we can guarantee the time spent and quality of every processing. We can do three times tempering to stabilize the dimensions of the bearings, which is quite different from other bearings manufacturers.
3. Quality control advantage
All the bearing parts are 100% strictly inspected before and during production including Metallurgical testing, crack detection, roundness, hardness, roughness and g++eometric dimensions.
4. All of bearings meet the ISO international standard.
5. Appearance Technology Advantage
we can provide light chamfer, black chamfer, black chamfer of the rollers. The bearings are produced all according to customer's requirements.
6. Service Advantage
Your satisfaction is our biggest goal. From quotation to the final packing and transport, we provide the quickest and most satisfactory services to every customer.
We participate Canton Fair,Shanghai Auto Mechanika Fair,Professional Auto Parts Fair annually.
Welcome Inquiry and order !
Thank you!
Guangzhou Wafangdian Bearing Co., Ltd. is a professional bearing company, belongs to Liaoning Wafang Dian Aoli Yuan Bearing Manufacturing Co. Ltd, , locates in Wafangdian north Gongji street, covers an area of more than 50000 square meters, over 300 staffs work in the factory. The annual production is more than 10 million sets of various bearings.
We have more than 30 years bearing manufacturing experience, execute strict and responsible quality control. Our products are: Deep groove ball bearing, tapered roller bearing, cylindrical roller bearing, spherical roller bearing, thrust ball bearing, needle bearing, self-aligning ball bearing, angular contact ball bearing, pillow block bearing, wheel hub bearing, clutch bearing, composite bearing and all kinds of non-standard bearings. Our bearings are low noise, long working life, high precision, high speed, heavy duty, good temperature resistance, widely used in automobiles, machine tools, mining, oil field, paper making, cement plant, power plant, steel mill, construction machinery and many other industries.
We are strong in research and development. We can design and produce bearings with drawings or samples to meet customers' specific needs. OEM services are also provided with customers' authorization. Small orders are accepted, free samples are available. We guarantee high quality, competitive prices, on-time delivery, fast response. Welcome all distinguished guests at home and abroad to contact us for business, looking forward to working with you hand in hand, create more brilliant future together!
