| Prod Model: |
BJ1107B1, BJ1107D1 |
| Main Material: |
Stainless Steel, Aluminium Alloy |
| Applicate: |
for Bone Surgery |
| Color: |
Black |
| Certificate: |
Ce, FDA, ISO |
| Packing: |
Sterilized Case or Carton Case |
Product Description
Company Information
| Basic Information |
| Company Name | Shanghai Bojin Medical Instrument Co., Ltd. |
| Business Type | Manufacturer exporter |
| Product/Service | Surgical Power Tools & Accessories/ Portable X-Ray Fluoroscopy Instrument |
| Number of Employees | 101 - 200 People |
| Brand Names | Bojin |
| Year Established | 1993 |
| Factory Size (Sq.meters) | 3000-5000 square meters |
| Factory Location | No. 125, Longpan Road, Jiading Dist,Shanghai,China |
| QA/QC Responsibility | In House |
| Number of R&D Staff | 5 - 10 People |
| Nnmber of Engineers staff | 5-10 |
| Monthly Capacity | 500 to 999 Pieces |
Packaging & Shipping
Packaging Details: Aluminum case or Carton packing for your selection.
Delivery Detail: Within 3 days after payment.
medical acetabulum reaming drill ream recharge deluxe
Application:
For application in cutting bone in joint surgery.
With the perfect shape of ergonomic design, the whole unit is autoclavable.
The advanced motor has a very low noise , which cuts steadily and quickly.
There is no damage for soft tissue.
The warranty period is 2 years together with lifetime maintenance.
A variety of different thickness and the length of the saw blades are for your selection.
Common length are 70mm,90mm and 100mm,common thickness are 0.8mm,1.0mm,1.2mm and 1.27mm.
Saw blade can also be customized according to your request.
Specification:
| Output power | ≥75w |
| Speed(r.p.m) | 0-280 |
| Oscillations (osc/min) | |
| Torque(Nm) | 6.5 |
| Operation(V) voltage | 14.4 |
| Sterilization | 135°C |
| Swings (°) | / |
| Noise(db) | ≤40 |
Standard Configuration:
1. One handpiece
2. One battery
3. One charger
4. One saw blade
5. One Aseptic battery transfer ring
6. One Operating manual
7. One Guarantee Card
Warranty:
The handpiece guarantees for two years, the battery and other fast consumption items guarantee for 3 months.
Advantages:
1.Our whole power tool can be autoclavable.
2.We can autoclavable for 135 °C (Improved type ≤ 155 °C ),with 1.6Mpa,in this way the bacilli and virus which can not killed by the suffocating will be killed.
3.We use environmental friendly nickel-metal hydride battery.
4.The machine has very low noise.
5.Our products has 2 years warranty period and lifetime maintenance.
Notes:
1.Sterilize temperature ≤ 135 °C (Improved type ≤ 155 °C ),if the temperature is over 135 ° C , the motor will be damaged.
2.Normal bone drill can only hold drill bits less than 6mm,acetabulum reaming drill with big torque,rpm is around 300,canulate drill is used with nail or K wire ,rpm is around 600.
3.The battery needs to be get out of the power tool after surgery.Otherwise the small automatic discharge of the electric will make the life of the battery short.
4.The battery cannot be sterilized ,it is not autoclavable.
5.The cranial bur must be washed right after the surgery by purger in order to avoid the blood stick in the bur,then we should make it dry.
6.The battery space in the handpiece of the tool should not have any water.
7.The cranial bur blade is made of medical stainless steel,in order to avoid brokage,so it is flexible and not very hard,it attrites easily,we advice customers to use each blade for only 1 surgery.
Established in 1993 and headquartered in Shanghai, Bojin, as an advanced orthopedic equipment manufacturer and solutions provider, Bojin focuses on the development and marketing of orthopedic-purpose motor products, X-ray imagescopes, treatment apparatus, and supporting surgical tools/parts. It has more than one hundred types of orthopedic products under 8 series, which have received QC certification of 3C, ISO9001, ISO13485, CE of the EU, and FDA Registry 3008787426. Its mission is to satisfy the needs of patients and medical care with innovative high-tech products and therefore become a promoter of people's orthopedic health. It has built a healthy sales and services network thanks to its 200 dedicated employees in the marketing companies or teams in more than 4countries and regions across North America, Europe and Asia. Its products are used in more than 60 countries and, in particular, in more than 20000 Chinese medical institutions 70% of which are 3A-rated hospitals. Bojin respects professionalism and talents and values core technology R&D. Its R&D team accounts for up to 20% of its staff, for it is fully aware that its top-notch professionals provide for the healthy operation of the company, the steady supply of high-quality medical equipment and comprehensive services for its global customers. Its innovation in products and solutions reduce social medical costs and therefore lessen the financial burden of patients. In the spirit of valuing life and health, Bojin, with a strong sense of social responsibility, are dedicated to innovating technology and upgrading product quality, thus ultimately helping improve the health of larger population. Its development is, as always, dependent upon technological innovation, common endeavor of the staff, and constant improvement of management philosophy. Each step forward has witnessed the staff's resilience and entrepreneurship, which, in turn, promotes the company's development and fortifies the staff's confidence in the company's prospect.
