Brand: |
Austter |
Engine: |
Loncin G420f(D) |
Chip Capacity: |
Fresh 100mm, Dry 65mm |
Blade: |
Skh-51 Material |
Chip Type: |
Rotor Type |
Feeding Type: |
Gravity Feeding |
20gp Container: |
30 Units |
40hq Container: |
72 Units |
Delivery Time: |
10 Days |
Warranty: |
2 Years |
Certification: |
TUV-Ce-MD, Ce-EMC, RoHS, PAHs, Noise |
Product Description
Function1.Covering bare soil, prevent dust; Inhibit the growth of weeds, moist soil;
2.Wet compost or natural rotten improved soil, good potting soil organic manure;
3.Plant eating animal feed, edible fungus cultivation base;
4.The pulp and man-made plank material; Biofuels, etc.
Features
1. Sufficient power from Loncin G420F(D).
2. SKF ball bearing from Sweden.
3. GATES driving V-belts from United States.
4. SKH-51 drum blades from United States.
5. Schneider emergency switch from France.
SPECIFICATIONSChip system |
Chip type | Rotor type |
Chip capacity | Fresh 100mm, dry 65mm |
Rotor width | 240mm |
Rotor diameter | 215mm |
Working RMP | 2400 rpm |
Rotor housing inlet size | 240*160mm |
Rotor housing outlet size | 252*78mm |
Drum blade | 2 pcs - 240*46*9mm |
Counter blade | 1 pc - 250*50*14mm |
Blade material | SKH-51 |
Bearing | SKF BOX ball bearing from SWEDEN |
Belt | GATES belts from UNITED STATES |
Frame system |
Frame type | Maneuverable |
Handrial height | 715mm |
Wheel | 16*4.5-8 tube tire |
Gasoline engine |
Brand | Loncin |
Model | G420F(D) |
Type | Single cylnder, 4-stroke, Forced air cooling, OHV |
Rated power | 9 kw/3600rpm |
Fuel consumption(g/kw.h) | ≤395 |
Idle speed | 1800±150 |
Displacement(cc) | 420 |
Starting Mode | Recoil start / Electric starting |
Fuel tank | 6.5L |
Oil tank | 1.10L |
Oil alarm | Yes |
Fuel/Oil type | Use unleaded gasoline with a pump octane rating of 86 or higher./10W-30, 4-stroke oil |
Dimension(L×W×H) (mm) | 405×452×443 |
Net weight(kg) | 32(35) |
Packing |
Packing method | Plywood case |
Packing size | 1115*665*1105mm |
Gross weight | 200kg |
20ft loading quantity | 32 units |
40HQ loading quantity | 72 units |
