| Price: | US $ 0.09/Piece |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 500/Piece |
| Pay Type: | L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: | BR-001 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Working Temperature: -100 To +200: | Friction Coefficient: 0.05~0.22 |
| Bearing Structure: | Solid Bearing |
| Type Of Lubricant: | Oil-Lubricated Bearing |
| Bushing Material: | Bronze |
| Bearing Direction: | Thrust |
| Lubricating Film Thickness: | Thick Film Lubrication |
| l Type | Chemical Composition(%) | Physical Property | ||||||||
| Fe | C | Cu | Sn | Zn | Pb | Others | Density | Oil% | HB | |
| Cu663 | < 0.5 | 0.5~2.0 | Rest | 5~7 | 5~7 | 2~4 | < 1.5 | 6.4 | ≥18 | 20~50 |
| Cu660 | < 0.5 | 0.5~2.0 | Rest | 5~7 | 5~7 | < 0.1 | < 1.5 | 6.4 | ≥18 | 20~50 |
| Cu9010 | < 0.5 | 0.5~2.0 | Rest | 8~11 | - | - | - | 6.4 | ≥25 | 25~55 |
| CuFe | Rest | - | 18~22 | - | - | - | <3 | 6 | ≥18 | 30~60 |
| Fe | Rest | <1 | - | - | - | - | <3 | 6 | ≥18 | 30~60 |
Inner Packing:
1. PP film tubes(OD over 25mm)& plastic bags(OD less than 25mm)
2. 50 or 100 pcs/platic bag
Carton:
360*360*240mm
360*360*180mm
360*240*180mm
Pallet:
18 cartons/pallet (1.2*0.8*1=0.96 m3), about 800 kg/pallet
