Outdoor High Definition P6 Full Color LED Screen
| Price: |
US $ 215-300/Box |
| Min Order: |
1/Box |
| Pay Type: |
T/T |
| Prod Model: |
P6 |
| Module Size: |
192*192mm |
| Cabinet Size: |
576*576mm |
| Module Resolution: |
32*32dots |
| Cabinet Resolution: |
96*96dots |
| Screen Brightness: |
6000CD/M2 |
| Controller: |
Nova/Linsn |
| Tube Chip Color: |
Full Color |
| IP Rating: |
IP65 |
| Pixel Configuration: |
1R, 1G, 1B |
| Display Function: |
Video Display |
| Average Power Consumption: |
350W / m² |
| Scanning Mode: |
1/8 Scan |
| Display Type: |
LED Video Display |
| Application: |
Advertising |
| Certification: |
CCC |
| Pixel Pitch: |
6mm |
| Pixel Density: |
27777 |
Product Description
P6 SMD Outdoor Full Color LED Display Screen Durable fresh color and high brightness by adopting high quality leds. . Energy-saving 29% by using high efficiency IC driver, high brightness leds and improved PCB. . Great uniformity , contract ratio and screen flatness. . Anti-UV module mask, Anti-Oxidation module frame with protection from deformation. . IP65 protection grade, durable nature enables the screen to work in all outdoor weather conditions.| Technical Specifications |
| NO | Product name | P6 led display |
| 1 | Pixel Pitch(mm) | 6mm |
| 2 | Pixel configuration | 1R1G1B/ SMD 3535 |
| 3 | Pixel density | 27778dots/m2 |
| 4 | Brightness | 6500cd/m2 |
| 5 | Module size(W*H) | 192*192mm |
| 6 | Module Resolution (W*H) | 32 dots x 32dots |
| 7 | Module weight | 500g |
| 8 | Cabinet size (W*H) | 576mm×576mm |
| 9 | Drive IC | MBI5124 |
| 10 | Drive mode | 1/8scan |
| 11 | Viewing Angle(V/H) | 110ºC |
| 12 | Grey Scale | 65536 degree |
| 13 | Life time | >100,000 Hours (50%) |
| 14 | MTBF | >50,000 Hours |
| 15 | Operating Voltage | AC110V/220V±10% |
| 17 | Screen Power Consumption | Max: 800w/m2; Average:270w/m2 |
| 18 | Input Power Frequency | 50/60Hz |
| 19 | Operating temperature | -30--60ºC |
| 20 | Humidity | 10%-95% |
| 21 | Refresh Rate | ≥1200HZ |
| 22 | Control Method | Synchronized with computer monitor |
| 23 | Color Temperature | 6500K-9500K |
| 24 | LED control system | LINSN,Nova-star,Colorlight is selectable |
| 25 | Control Distance | 100 m (no repeating); Optical fiber transmission: 500m- 15km |
| 26 | Accepting signal with video processor | PAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI |
| 27 | Systems Operating Platform | Windows Xp / Windows 7 / windows 8 /8.1 / windows 10 |
Professional production:Full Color LED Display,Indoor LED Display,Outdoor LED Display,Rental LED Display,Outdoor SMD LED Display,Outdoor DIP LED Display,Full Color LED Display Module,Single Color LED Display Module,Transparent LED Display,Advertising LED Screen.Company descripition:
Coree was founded in 2003. Our company strives to deliver stunning LED solutions that can satisfy all customer requirements. Standardization and flexible production allow us to offer competitive prices for a wide range of high quality products. Our valued clients can enjoy the benefits of attentive service and prompt delivery. For the past 6 years, we have made steady progress. Ingenuity and perseverance have firmly established us as pioneers in the LED display industry. Our company is dedicated to the research and development of LED related technologies.Our products have been widely used in airports, schools, transport facilities, railway stations, stages, sports stadiums, community gardens, commercial plazas, government agencies, hospitals, the monitoring center and advertising and entertainment venues ect.
Shanghai Coree Electronic Technology Co., Ltd, was established in 2003. It has been committed to the LED displays research and development, manufacturing, wholesale and overall engineering services for high-tech enterprises. Shenzhen Coree Electronic Technology Co., Ltd, the company production base is located in Chinese high technology intensive Baon district of Shenzhen. We can provide customers with a variety of models of high quality LED display products.
Shanghai Coree Electronic Technology Co., Ltd is located in Pudong Sanzao urban industrial park. We have standard factory buildings has for research, development, business, testing, assembling and aging test. Shenzhen production base has a professional technical team and equipment, can efficiently produce all kinds of LED display products, and each product must go through rigorous functional testing to ensure the quality of the supplied LED display products.
At present, Shanghai Coree Electronic Technology Co., Ltd has three series of productions, indoor and outdoor full color LED display series, expressway and traffic guidance display series, and transparent display series. Indoor full color display, small pixel pitch, high-definition, high refresh rate. Outdoor full-color display, full-Surface mount technology, high brightness, high density. Expressway and traffic guidance displays, according to national standard level of production, can normally work in ultra-high temperature, ultra-low temperature environment. Transparent display is divided into a louver display, 3D bead curtain display, soft crystal lattice display, so it makes LED display more artistic, more visually stunning.
Over the past decade, Shanghai Coree Electronic Technology Co., Ltd has "scientific and technological innovation, increasingly progressive" theory as guidance, constantly improving and innovation, better ourselves in continuous improvement in order to meet the social LED display of different styles and types of product demand. Presently, Shanghai Coree Electronic Technology Co., Ltd the company has developed higher Cost-Performance Ratio, stability and better product display, has provided a lot of custom products in the airport terminal display field and is widely used.
Our products have been widely used in airports, schools, transport facilities, railway stations, stages, sports stadiums, community gardens, commercial plazas, government agencies, hospitals, the monitoring center and advertising and entertainment venues ect.
