| Price: | US $ 8-10/Piece |
|---|---|
| Min Order: | 1/Piece |
| Pay Type: | L/C,T/T,Western Union,Paypal,Money Gram |
| Prod Model: | DBXTVO8 |
|---|---|
| Temperature: | -50 Degree |
| HD TV: | High Density |
| Brightness: | High Bright |
| Standard: | Ce RoHS |
| PCB: | IP65 |
| Hot Material: | +80 Degree |
| Tube Chip Color: | Full Color |
| IP Rating: | IP65 |
| Pixel Configuration: | 1R, 1G, 1B |
| Display Function: | Market Display |
| Average Power Consumption: | 350W / m² |
| Scanning Mode: | 1/8 Scan |
| Display Type: | LED Video Display |
| Application: | Advertising |
| Certification: | ETL |
| Pixel Pitch: | 8mm |
| Pixel Density: | 15625 |
| Technical Specification | |||
| 1 | Pixel | Package Mode LED | SMD 3535 |
| Pixel Configuration | SMD 3in1 | ||
| Wave length (nm ) | R:626-628,G:518*520,B:466-468 | ||
| 2 | Module | Module size (mm ) | 128*256mm |
| Module Pixel(dot ) | 16*32 | ||
| 3 | Electricity parameter | pixel density (dots/m2 ) | 15625 |
| white balance brightness (cd/m2) | 6000-10000 | ||
| LED driving method | 1 /4 scanning | ||
| Best Viewing Distance | 8 -200m | ||
| LED lamp | Epistar | ||
| Working temperature( degree ) | -50~+80 | ||
| screen life time (hours) | >=100,000 | ||
| whole display flatness | less than 1mm juncture | ||
| Maintenance way | back maintenance | ||
| Power supply | 220 V | ||
| power consumption (w/m2) | ≤ 1100 | ||
| Input Voltage | 88-132VAC/176-264 VAC;47-63Hz | ||
| Brightness Control | Manual 256 level & Auto. 8 level | ||
| Dot Defects Rate | ≤0.0001 | ||
| Operating Temp.& RH | -50ºC~80ºC / 20%~90%RH | ||
| Strorage Temp. & RH | -40ºC~85ºC / 10%~95%RH | ||
| Input Signal | RF,S-Video,RGB,RGBHV, YUV,YC,COMPOSITION,etc. | ||
| Communication Cable | CAT5(≤100m); Optical Fiber(500m-15000m) | ||
| Terms and Conditions | |||
| 1 | Price | EXW Price (not including any extra shipping fee or doucment fee) | |
| 2 | Payment | 50% as deposit, ( During the production, client can not cancel the order, if cancel, the prepayment will be belong to the Seller ); 50% as balance before sending goods | |
| 3 | Inspection | By in house Quality Assurnce Dept and self certification. Customer could request the third party to make advanced inspection at our factory | |
| 4 | Delivery | About 9-15 working days after receiving the advanced payment | |
| 5 | LED lamp | All LED lamps used are Epistar made or stated | |
| 6 | Power supply | 240 V / 220V / 110V | |
| 7 | Storage Condition | Don't keep the goods under Damp and Dark environment over half years. | |
| 8 | Warranty | Module Quality three years,control card and power supply one year.Counting from the goods arrival at destination port.(Excluding problems caused by human damage and improper storage.) | |
| 9 | In-sales service | 1).Offer free software , free screen installation manual and free controller system manual 2).The normal temperature : -50ºC ~+80ºC,the power supply contains adjustable temperature sensor to better protect the screen from too hot temperature 3).Offer free CAD drawing for customers to do steel structure | |
| 10 | The rights and obligations of Seller | 1). Detailed understanding of project requirements, designed to meet the customer needs of the LED display, as well as provided installation diagram to the Buyer as reference. 2). The program must be in strict accordance with the contract signed . Production of products are subject to change, it must consult with the Buyer, after Buyer written consent, it can change. 3). Seller should send someone tracking the production, installation, use, identifying problems and timely treatment. 4). Seller shall provide free training services and assign someone to be responsible for contact with the service matters. Main training basic structure of the device, the main components of the structure and handling. Daily use operation, maintenance and management, common faults such as that is not the same type of equipment used, the equipment needed to function accordingly technical training , training Location: in Seller's factory. | |
| 11 | After-sales service | 1).Completion acceptance, The whole screen warranty 3 years(Module Quality 3 years, control card and power supply 1 year). Warranty: 3 years, counting from the goods arrival at destination port. Warranty period, simple questions can be solved by telephone or network technical guidance and support, if not, Seller should arrange technical personnel arrived at buyer's place soon after both sides discussion. 2). After the warranty period , equipment maintenance can be negotiated and confirmed by both seller and buyer (Change the material price according to the market price charged). | |
| 12 | Validity | This quotation is valid from 2017.12.20 to 2018.03.28 | |
