| Prod Model: |
P100 |
| Standard: |
ISO1452, DIN8063 |
| Pressure: |
Pn16, Pn10 |
| Material: |
PVC |
| Hardness: |
Hard Tube |
| Hollow: |
Hollow |
| Shape: |
Round |
| Usage: |
Agricultural Irrigation Pipe |
| Type: |
Glue & Rubber Ring |
| Color: |
Grey, Blue |
Product Description
| Standards of UPVC Testing Material |
| Index Name | Unit | Index |
| Colour | | Grey |
| Density | kg/m3 | 1330-1460 |
| Vicat Softening Temperature | ºC | >=80 |
| Hydraulic Test | | No break,no leakage |
| Longitudinal Reversion | % | <=5 |
| Dichloromethane Soaking | | No damage on surface of sample |
UPVC Pipe advantage details
- 30% higher flow compared with same size steel pipe.It is also the first choice material for drainage and sewage applications because of aging resistance
- UPVC material can speed up schedule of construction and decrease the cost
- UPVC Piping system is not easy to block because of smoothy interface. Meanwhile it is easy to inspect
Our Service
- Any inquiries will be replied within 24 hours
- Professional manufacturer
- OEM is available
- High quality, standard designs, reasonable&competitive price, fast lead time
- Faster delivery: Sample will be prepared in 2-3days
- Shipping: We have strong cooperation with DHL, TNT, UPS, MSK, China Shipping, etc
- You can also choose your own shipping forwarder
| | Pressure |
OD
(mm) | 0.5Mpa | 0.6Mpa | 0.63Mpa | 0.8Mpa | 1.0Mpa | 1.25Mpa | 1.6Mpa | 2.0Mpa | 2.5Mpa |
| Thickness | | Thickness | | Thickness | | Thickness | | Thickness | | Thickness | | Thickness | | Thickness | | Thickness | |
| 10 | | | | | | | | | | | | | | | | | 1.5 | |
| 12 | | | | | | | | | | | | | | | | | 1.5 | |
| 16 | | | | | | | | | | | | | 1.5 | | | | 1.8 | |
| 20 | | | | | | | | | | | | | 1.5 | | 2 | | 2.3 | |
| 25 | | | | | | | | | | | 1.5 | | 1.9 | | 2.3 | | 2.8 | |
| 32 | | | | | | | | | 1.6 | | 1.9 | | 2.4 | | 2.9 | | 3.6 | |
| 40 | | | | | 1.5 | | 1.6 | | 1.9 | | 2.4 | | 3.0 | | 3.7 | | 4.5 | |
| 50 | | | | | 1.6 | | 2.0 | | 2.4 | | 3.0 | | 3.7 | | 4.6 | | 5.6 | |
| 63 | 1.6 | | 1.9 | | 2.0 | | 2.5 | | 3.0 | | 3.8 | | 4.7 | | 5.8 | | 7.1 | |
| 75 | 1.9 | | 2.2 | | 2.3 | | 2.9 | | 3.6 | | 4.5 | | 5.6 | | 6.9 | | 8.4 | |
| 90 | 2.2 | | 2.7 | | 2.8 | | 3.5 | | 4.3 | | 5.4 | | 6.7 | | 8.2 | | 10.1 | |
| 110 | | | | | 2.7 | | 3.4 | | 4.2 | | 5.3 | | 6.6 | | 8.1 | | 10 | |
| 125 | | | | | 3.1 | | 3.9 | | 4.8 | | 6.0 | | 7.4 | | 9.2 | | 11.4 | |
| 140 | | | | | 3.5 | | 4.3 | | 5.4 | | 6.7 | | 8.3 | | 10.3 | | 12.7 | |
| 160 | | | | | 4.0 | | 4.9 | | 6.2 | | 7.7 | | 9.5 | | 11.8 | | 14.6 | |
| 180 | | | | | 4.4 | | 5.5 | | 6.9 | | 8.6 | | 10.7 | | 13.3 | | 16.4 | |
| 200 | | | | | 4.9 | | 6.2 | | 7.7 | | 9.6 | | 11.9 | | 14.7 | | 18.2 | |
| 225 | | | | | 5.5 | | 6.9 | | 8.6 | | 10.8 | | 13.4 | | 16.6 | | | |
| 250 | | | | | 6.2 | | 7.7 | | 9.6 | | 11.9 | | 14.8 | | 18.4 | | | |
| 280 | | | | | 6.9 | | 8.6 | | 10.7 | | 13.4 | | 16.6 | | 20.6 | | | |
| 315 | | | | | 7.7 | | 9.7 | | 12.1 | | 15.0 | | 18.7 | | 23.2 | | | |
| 355 | | | | | 8.7 | | 10.9 | | 13.6 | | 16.9 | | 21.1 | | 26.1 | | | |
| 400 | | | | | 9.8 | | 12.3 | | 15.3 | | 19.1 | | 23.7 | | 29.4 | | | |
| 450 | | | | | 11 | | 13.8 | | 17.2 | | 21.5 | | 26.7 | | 33.1 | | | |
| 500 | | | | | 12.3 | | 15.3 | | 19.1 | | 23.9 | | 29.7 | | 36.8 | | | |
| 560 | | | | | 13.7 | | 17.2 | | 21.4 | | 26.7 | | | | | | | |
| 630 | | | | | 15.4 | | 19.3 | | 24.1 | | 30.0 | | | | | | | |
| 710 | | | | | 17.4 | | 21.8 | | 27.2 | | | | | | | | | |
| 800 | | | | | 19.6 | | 24.5 | | 30.6 | | | | | | | | | |
| 900 | | | | | 22 | | 27.6 | | | | | | | | | | | |
| 1000 | | | | | 24.5 | | 30.6 | | | | | | | | | | | |
Changzhou Xita Plastic Co., Ltd is a professional supplier of UPVC/CPVC/PE/PPR Pipes, pipe fittings, valves. Plastic piping systems such as pipes, fittings and valves is widely used in water supply, chemical industry, water treatment, environmental protection, pharmaceutical area etc.
We could provide products as follows:
1. PVC pipe fittings-Cement PN10: 20mm~400mm
2. PVC pipe fittings-rubber ring fittings PN10: 63mm~355mm
3. PVC pipe fittings-Cement PN16: DN15~DN200
4. PVC Valves: Ball valves, true union valves, butterfly valves, check valves, bottom valves, Y strainers
5. PPR pipe fittings
6. PE pipe and fittings
7. Distribution: Drier for injecion machines; PVC/PE foam tapes for sealing; PET tapes
We insist in the principal of ""Quality First, Clients First". Your satisfaction is our eternal pursuit. We Strictly follows ISO9001 quality system to arrange manufacturing. With high-class raw material, strict quality control in both the workshop and laboratory with various professional testing equipment, Xita Plastic ensures that every single product meets the corresponding inspection standard.
Our sales staff is experienced in plastic piping area for 9 years. We will give you suggestions for your better choice.
"Xita Plastic" warmly welcomes friends and clients all over the world for further cooperation.
