| Price: | Negotiable/Piece |
|---|---|
| Trade Terms: | FOB |
| Min Order: | 1SET |
| Pay Type: | L/C,T/T |
| Prod Model: | TSY-37G |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Application: | Machinery & Hardware |
2.The inverter of main motor & travel motor is YASKAWA-H1000 (From Japan)with waterproof, dustproof treatment.
3.Most of electrical component are Schneider and Siemens.
4.The brand of main motor and travel motor are WANDER(Chinese Brand, OEM OF SIEMENS).
5.The angle and height of the main flywheel can be adjusted by manual control button.
Remark
1.The wire tension and cutting current is closed loop automatic controlled by PLC and inverter.
2.The cutting process can be automatical controlled accurately.
3.The movement and rotation of the cutting head is driven by motor with position Limitation Protection.
4.Machine protection functions including:wire broken,Machine overload,cutting finished,and others malfunction happened.
5.Display an saving with digitization:the value of cutting current,linear speed and moving speed indicated on the panel,and the cutting time can be saved.
6.The machine without phase request.It is needn't to change and distinguish.
| Technical Parameter(For granite and marble quarry) | |
| Total power | 40kw |
| Main motor power | 37kw/50HP |
| Cutting head rotation | 360 |
| lateral movement | 1.8m |
| Cutting head shifting | 415mm |
| Line speed | 0-40m/s |
| Travelling speed | 0-150m/h |
| Length of trail | 2mx3 |
| Working temperature | -15C to +40C |
| Dimension of the machine | L=1865mm, W=1267mm, H=1430mm |
| Net weight | 1.95T |
