| Prod Model: |
A1, 4A2, 6A9, 9A3, 11V9, 12A2 |
| Markets: |
North America,Eastern Europe,Western Europe |
| Material: |
Diamond |
| Abrasive: |
Superabrasive |
| Shapes: |
Edge Shape |
| Types: |
Centerless Grinding Wheel |
| Grain Size: |
240# |
| Cylindricity: |
<1 |
| Circular Degree: |
<1 |
| Technics: |
Sinter |
| Working Style: |
Tool Grinding |
Product Description
Sumeng abrasives is one of the largest full line manufacturers of vitrified resin, rubber and shellac bonded grinding wheels and superabrasive products in China.
Face Grind Vollmer
FACE GRINDING WHEELS FOR VOLLMER EQUIPMENT
D4A2 115mm x 11mm x 32mm D 280 R 100 B 1/8 W=1/8
B4A2 125mm x 3/8 x 32mm CBN 180 R 75 B 1/16 W=1/8
D4V2 125mm x 11mm x 32mm D 280 R 100 B 2mm W=4mm
B4V2 125mm x 13mm x 32mm CBN 180 R 75 B 2mm W=4mm
D12V9 125mm x 12mm x 32mm D 240 R 100 B 1/16 S=20°
B12V9 120mm x 12mm x 32mm CBN 180 R 100 B 1/4 S=30°
Side Grind Vollmer
SIDE GRINDING WHEELS FOR VOLLMER EQUIPMENT
D4A1 3 x 10mm x 32mm D 220 R 75 B 3/16 U=5/32
B4A1 100mm x 10mm x 32mm CBN 120 R 50 B 5/32 U=5/32
Face Grind Vollmer Dornhan & Widma
FACE GRINDING WHEELS FOR VOLLMER DORNHAN AND WIDMA EQUIPMENT
D4A2 100mm x 3/8 x 25mm D 240 R 125 B 1/16 W=1/8
B12V9 125mm x 13mm x 25mm CBN 220 R 100 B 1/16 S=20°
D4V2 125mm x 11mm x 25mm D 240 R 125 B 2mm W=4mm
B4B2 175mm x 13mm x 50.8mm CBN 120 R 100 B 2mm W=1/4
Top Grind Vollmer Dornhan & Widma
TOP GRINDING WHEELS FOR VOLLMER DORNHAN AND WIDMA EQUIPMENT
D6A2 100mm x 3/4 x 25mm D 180/400 R 100 B 1/4 W=5mm
B6A2 4 x 3/4 x 25mm CBN 120/220 R 100 B 1/4 W=1/4
D6A2 125mm x 20mm x 50.8mm D 180/400 R 100 B 1/4 W=5mm
B6A9 100mm x 3/4 x 25mm CBN 150 R 100 B 3/16 U=1/4
Side Grind Vollmer Dornhan & Widma
SIDE GRINDING WHEELS FOR VOLLMER DORNHAN AND WIDMA EQUIPMENT
D4A1 3 x 9/16 x 20mm D 220 R 75 B 3/16 U=5/32
B4A1 100mm x 9/16 x 20mm CBN 120 R 50 B 5/32 U=5/32
Top Grind Walter Woodtronic
TOP GRINDING WHEELS FOR WALTER WOODTRONIC EQUIPMENT
D14B1 150mm x 8mm x 32mm D 180/400 R 125/100 B 1/4 U=5mm
B14B1 200mm x 8mm x 32mm CBN 150/240 R 100 B 1/4 U=5mm
Taizhou Sumeng Grinding Wheel Co., Ltd. (including Jiangsu Subei Grinding Wheel Factory Co. Ltd, Bondflex Abrasives Co Ltd, SUZHOU SAILI PRECISION TOOLS CO Ltd) is leading factory specialized in manufacturing bonded abrasive products and Superabrasives tool, large O. D. Reinforced Cutting Wheels, Crankshaft Grinding Wheels, Cutting and Grinding Discs, Diamond & CBN Wheels, TCT Saw Blades, Diamond Tools etc.
