| Prod Model: |
BL220-2P |
| Brazing Diameter: |
500-2300mm |
| Power: |
600W |
| Weight: |
210kg |
| Brazing Capacity: |
250-550PCS/Hour |
Product Description
BL-2P/3P series welding frame is semi-automatic welding machine.Manually sent segment,manually put silver solder,manually put soldering flux,and human-assisted segment separating,other welding steps will be finished automatically.
Configuration:
1.Segment automatic fixing system.Machine can automatic fix the segment to the welding position.
2.Segment manually centering system.Manually adjust the welding position of the segment before the welding.
3.Human-assisted segment separating system.
4.Blade lock protraction system.Prevent damage of the cupreous part when operator rising the saw blade.
| Model | BL220-2P/3P | BL350-2P/3P |
| Brazing diameter(mm) | 500-2300 | 800-3800 |
| welding error(verticality)(mm) | ≤±+0.03 | ≤±0.03 |
| welding error(linearize)(mm) | ≤±0.03 | ≤±0.03 |
| brazing capacity(pc/h) | 250-550 | 200-500 |
| air pressure(mpa) | 0.6 | 0.6 |
| hydraulic pressure(mpa) | ≥0.2 | ≥0.2 |
| power(w) | 600 | 1500 |
| water consumption(m³/h) | 2 | 2 |
| weight(kg) | 210 | 250 |
| size(mm) | 100x800x1900 | 1100x800x2400 |
Delivery time:within 30 days after receiving your T/T advance payment.
Warranty period:12 months excluding the wearing parts
Pls visit our website: www.quarryingtools.com for more product details.
If you have any questions,pls feel free to ask me.
