Home Toolbuy Products Single-Acting Telescopic Cylinder Type Hydraulic Cylinder for Agricultural Machinery Cylinder
Single-Acting Telescopic Cylinder Type Hydraulic Cylinder for Agricultural Machinery Cylinder
| Price: |
US $ 100-200/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,Western Union,Paypal,Money Gram |
| Prod Model: |
no standard |
| Seal: |
Kaden, Hallite, Parker, Nok, SKF etc |
| Mounting Type: |
Earring-Trunnion, Double Trunnion, Double Earring |
Product Description
Single-Acting Telescopic Cylinder Type Hydraulic Cylinder for Agricultural Machinery Cylinder
A. Hydraulic cylinders introductions
1.Seals:Parker/Nok/Hallite/Taiwan ;
2.Rod :Chrome plated and quenched.Has good mechanical properties, long service life;
3.Cylinder:Honing machining /boring /rolling;
4.Ballblast for paint ;
5.Short Delivery Time ;
6.Warranty:One year;
B. Mounting way:
1.Front and end of earring;
2.Head fixed with flange;
3.End fixed with flange;
4.Vertical to axis foot type;
5.Middle fixed with pendulum shift;
6.End with single earring;
7.According to your demand.
C. Price and technical solutions :
In order for you to get a better price and technical solutions.Please provide the following required parameters:
1.Bore diameter;
2.Rod diameter;
3.Stroke;
4.Working pressure;
5.Front and back end mount type;
6.Using frequency;
7.Work Environment;
Certainly, you can provide drawing and product photos so that we can understand your meaning more conveniently, or you can also send us sample and we produce for you according to your sample.
D. Quality control - All specification is designed by professional engineer
- All material is high quality-Seal kits are purchased from USA, Japan, UK and Sweden.
- All material is processed by skilled workers and advanced CNC lathe
- All cylinders are 100% tested before package to ensure every cylinder is qualified for its purpose
- Package is air cushion film for each cylinder and steel case for all cylinders to ensure goods can arrive at customer safely
- One year warranty and life long time follow up service is offered to solve any problems you met when use our products
| HS Code | 8412210000 |
| Application | Dump truck,Tipper,Trailer |
| Material of cylinder tube | Alloy steel |
| Seal | Kaden,Hallite, Parker,NOK,SKF etc |
| Coating | All tubes are chrome plated |
| Working pressure | 10MPa-32MPa |
| Stroke | 3000mm-12000mm |
| Color | Black,Blue,Yellow,White,Red etc |
| Mounting Type | Earring-trunnion, double trunnion, double earring (eye end) |
| Plunger | 20#, 45# steel with high frequency quenching |
| Certification | ISO9001:2008 ,SGS, TS16949 |
| Package | shrink film, pallet, plywood case and carton box |
| Warranty | One year after shipping arrival |
| Main export market | USA, Canada, South Korea, Russia, Australia, Indonesia, Malaysia, Fiji Island, Kenya, Philippines, Bolivia, the United Arab Unites,Singapore |
| Payment terms | T/T, L/C, West Union |
| Delivery time |
30 days after down payment |
