Stainless Steel Rigging Screw Fork&Fork

Name: Stainless Steel Rigging Screw Fork&Fork
Brand: tool-buy.com
SKU: 806947615
Availability: InStock
Rating: 4.4 (55 reviews)

Price:	US $ 0.2-80/Piece
Min Order:	100/Piece
Pay Type:	T/T,Western Union

Contact Supplier

WUDI SUPMETALS CO., LTD.

Showroom Product Company Profile

Prod Model:	XY-1001

Product Description

Rigging Screw Fork&Fork
Stainless Steel 304 and 316, steel

Art. No.	Thread Size	A (mm)	D (mm)	H (mm)	L1 (mm)	L2 (mm)	KG/100
XY-1001-0004	M4	5.5	4	8	110	170	3.6
XY-A1001-0005	M5	6.5	5	10	130	190	5.6
XY-B1001-0005	M5	7.5	5	9	130	190	4.7
XY-A1001-0006	M6	7.5	6	10	150	220	8.6
XY-B1001-0006	M6	8	6	10	150	220	8.3
XY-1001-0008	M8	11	8	11	165	240	15.5
XY-1001-0010	M10	12	9	14	190	280	28
XY-1001-0012	M12	14	12	20	245	360	53
XY-1001-0014	M14	15	12	22	270	390	64.5
XY-1001-0016	M16	17	16	26	310	450	118
XY-1001-0020	M20	20	19	30	360	510	203
XY-1001-0022	M22	30	22	46.5	472	653	448
XY-1001-0024	M24	30	25	49	520	750	638
XY-1001-0027	M27	34	28	54	595	830	752
XY-1001-0030	M30	40	32	62	660	915	948
XY-1001-0036	M36	44	36	70	730	1000	1366
