Standard & Durable Polyethylene Water Supply Pipe
| Price: |
US $ 3.6-248/Meter |
| Min Order: |
100/Meter |
| Pay Type: |
L/C,T/T,Western Union,Paypal |
| Prod Model: |
HB-WSPE |
| ODM: |
Supported |
| OEM: |
Supported |
| Standard: |
JIS |
| Morphology: |
Liquid |
| Cross-Section Shape: |
Round |
| Connection Type: |
Welding |
| Material: |
PE |
| Diameter: |
75mm—630mm |
Product Description
Standard & Durable Polyethylene Water Supply Pipe
Features:
• High corrosion resistance, resulting into a longer life.
• High impact strength
• Extremely light weight and hence easy to handle
• High flexibility
• High abrasion resistance
• Excellent water hammer characteristic helps, sustaining surges
• Excellent flow characteristics leading to significant energy savings.
• Shifting soils - no breakage
• Earthquake resistance
• No infiltration, helps maintaining the quality of fluids being conveyed
• No trenches needed, resulting into easy and economical installation
• High UV resistance to scaling and biological build up
• Allows fusion to eliminate leakages
• Emergency connection possible
Application:
• Water Supply System
1. Transportation and distribution system
2. House service connection
3. Geo-thermal pipe for room heating & hot water system
• Industrial
1. For Effluents, chemicals and treated/untreated waster disposal
2. As Hydro Transport System for handling and conveyance iron ore slurry, - coal / cement slurry and slurry transportation in mines
3. For conveyance of edible oil, fruit pulps, juices, milks and other food materials.
4. As ducts for ventilation and air conditioning
• Environmental Protection
1. Rehabilitation of existing sewer
2. Effluent and waste treatment plant pipes
3. Dust suppression piping systems in cement industry
4. Sand slurry disposal pipes in dredging
5. De-gassing pipes in water effluent marine outfalls
• Agriculture
1. Piping for submersible and jet pumps
2. Suction and delivery pipes
3. Sprinkler piping for irrigation
• Other
1. Transportation of chemicals, solids, gas and oils
2. Underwater pipelines. / Desalination plants
3. Bore wall delivery lines
4. Telecommunication cable ductin
HDPE Pipe For Water Supply |
Nominal outside
diameter Dn(mm) | PE80 Pipe | PE100 Pipe |
| Nominal wall thickness en(mm) |
| PN4 | PN6 | PN8 | PN10 | PN12.5 | PN6 | PN8 | PN10 | PN12.5 | PN16 |
| SDR33 | SDR21 | SDR17 | SDR13.6 | SDR11 | SDR26 | SDR21 | SDR17 | SDR13.6 | SDR11 |
| 20 | - | - | - | - | 2.3 | - | - | - | - | 2.3 |
| 25 | - | - | - | 2.3 | 2.3 | - | - | - | 2.3 | 2.3 |
| 32 | - | - | 2.3 | 2.4 | 3.0 | - | - | 2.3 | 2.4 | 3.0 |
| 40 | - | 2.3 | 2.4 | 3.0 | 3.7 | - | 2.3 | 2.4 | 3.0 | 3.7 |
| 50 | 2.3 | 2.4 | 3.0 | 3.7 | 4.6 | 2.3 | 2.4 | 3.0 | 3.7 | 4.6 |
| 63 | 2.4 | 3.0 | 3.8 | 4.7 | 5.8 | 2.4 | 3.0 | 3.8 | 4.7 | 5.8 |
| 75 | 2.6 | 3.6 | 4.5 | 5.6 | 6.8 | 2.9 | 3.6 | 4.5 | 5.6 | 6.8 |
| 90 | 2.8 | 4.3 | 5.4 | 6.7 | 8.2 | 3.5 | 4.3 | 5.4 | 6.7 | 8.2 |
| 110 | 3.4 | 5.3 | 6.6 | 8.1 | 10.0 | 4.2 | 5.3 | 6.6 | 8.1 | 10.0 |
| 125 | 3.8 | 6.0 | 7.4 | 9.2 | 11.4 | 4.8 | 6.0 | 7.4 | 9.2 | 11.4 |
| 140 | 4.3 | 6.7 | 8.3 | 10.3 | 12.7 | 5.4 | 6.7 | 8.3 | 10.3 | 12.7 |
| 160 | 4.9 | 7.7 | 9.5 | 11.8 | 14.6 | 6.2 | 7.7 | 9.5 | 11.8 | 14.6 |
| 180 | 5.5 | 8.6 | 10.7 | 13.3 | 16.4 | 6.9 | 8.6 | 10.7 | 13.3 | 16.4 |
| 200 | 6.2 | 9.6 | 11.9 | 14.7 | 18.2 | 7.7 | 9.6 | 11.9 | 14.7 | 18.2 |
| 225 | 6.9 | 10.8 | 13.4 | 16.6 | 20.5 | 8.6 | 10.8 | 13.4 | 16.6 | 20.5 |
| 250 | 7.7 | 11.9 | 14.8 | 18.4 | 22.7 | 9.6 | 11.9 | 14.8 | 18.4 | 22.7 |
| 280 | 8.6 | 13.4 | 16.6 | 20.6 | 25.4 | 10.7 | 13.4 | 16.6 | 20.6 | 25.4 |
| 315 | 9.7 | 15.0 | 18.7 | 23.2 | 28.6 | 12.1 | 15.0 | 18.7 | 23.2 | 28.6 |
| 355 | 10.9 | 16.9 | 21.1 | 26.1 | 32.2 | 13.6 | 16.9 | 21.1 | 26.1 | 32.2 |
| 400 | 12.3 | 19.1 | 23.7 | 29.4 | 36.3 | 15.3 | 19.1 | 23.7 | 29.4 | 36.3 |
| 450 | 13.8 | 21.5 | 26.7 | 33.1 | 40.9 | 17.2 | 21.5 | 26.7 | 33.1 | 40.9 |
| 500 | 15.3 | 23.9 | 29.7 | 36.8 | 45.4 | 19.1 | 23.9 | 29.7 | 36.8 | 45.4 |
| 560 | 17.2 | 26.7 | 33.2 | 41.2 | 50.8 | 21.4 | 26.7 | 33.2 | 41.2 | 50.8 |
| 630 | 19.3 | 30.0 | 37.4 | 46.3 | 57.2 | 24.1 | 30.0 | 37.4 | 46.3 | 57.2 |
| 710 | 21.8 | 33.9 | 42.1 | 52.2 | 64.5 | 27.2 | 33.9 | 42.1 | 52.2 | 63.6 |
| 800 | 24.5 | 38.1 | 47.4 | 58.8 | 72.7 | 30.6 | 38.1 | 47.4 | 58.8 | 72.7 |
| 900 | 27.6 | 42.9 | 53.3 | 66.2 | 81.8 | 34.4 | 42.9 | 53.3 | 66.2 | 81.8 |
| 1000 | 30.6 | 47.7 | 59.3 | 73.5 | - | 38.2 | 47.7 | 59.3 | 73.5 | - |
| 1200 | 36.4 | 57.1 | 70.6 | - | - | 46.2 | 57.1 | 70.6 | - | - |
We HUIBIN Industry is specialize in Stainless steel and other metal for more than 20 years. Bollard especially automatic & retractable bollard is our latest products.
Our bollard has been manufactured keeping in mind the corrosive nature of the tropical climate. All parts of bollards are hot DIP galvanized to prevent corrossion and smooth function even when submerged in water. To give a fine balance between aesthetics and security, all bollards come with an aesthetically pleasing stainless steel sleeve and Stainless steel top plate which easily merges with the environment. Our bollards are fast and are ideal for infrastructure requiring a high level of protection from forced impact, have the least distance to the point of impact and requires continuous operation. With spare kit a part of our standard supply, after sales service is always our priority.
---20 years focus on stainless steel;
---30+ tech support from all over the world;
---OEM & ODM Welcomed
In order to expand our business and to serve our customers better, we cooperate with many multi-national enterprises in depth and become strategic partners with them. We can offer customers "one station" service for mixture different items as per your purchasing plan, which can save your freight, capital and keep your goods all ways in good condition and low stock. We sincerely welcome domestic and foreign customers to visit the company guidance, negotiate business.
