Tungsten carbide saw tips usually used for process wood materials. as dry wood ,soft wood ,hard wood, original wood, solid wod, multiple wood, and nonferrous metal, most kinds of steel materials, granite, marble.
2. Grades available:
Grade
Equal to ISO Category Number
Performance
uses
Density
Bend Strength
Hardness
G/Cm3
N/mm2
HRA
YG3
K01
14.9-15.3
≥1180
≥90.5
sand-blasting nozzles Qualified for fine turning and half-fine turning when cast iron, non-ferrous metal, alloys as well as non-alloy materials cutting consecutively. Can make wire drawing of steel and non-ferrous metal. Also qualified for sand-blasting nozzles.
YG3X
K01
15.1-15.4
≥1300
≥91.5
YG6X
K10
14.8-15.1
≥1560
≥91.0
Qualified for machining of chilled cast iron, alloy cast iron, refractory steel and alloy steel. Also Qualified for the machining of common cast iron.
YG6A
K10
14.7-15.1
≥1580
≥91.0
YG6
K20
14.7-15.1
≥1670
≥89.5
Qualified for finish machining and semi-finish machining for the cast iron, non-ferrous metal, alloy and unalloyed materials. Also qualified for wire drawing for the steel and non-ferrous metal, electric drill for geology use and steel drill etc.
YG8
K20-K30
14.6-14.9
≥1840
≥89
Qualified for rough machining of cast iron, non-ferrous metal, nonmetal materials, drawing of steel, non-ferrous metal and pipes, various drills for geology use, tools for machine manufacture and wearing parts.
YT15
P10
11.1-11.6
≥1180
≥91.0
Qualified for rough machining, semi-finish machining and finish machining during consecutive machining of carbon steel and alloy steel.
YT14
P20
11.2-11.8
≥1270
≥90.5
Qualified for rough machining for rough face of carbon steel and alloy steel, half process during discontinuity cutting.
YT5
P30
12.5-13.2
≥1430
≥89.5
Qualified for rough machining for rough face of carbon steel and alloy steel and discontinuity cutting.
YW1
M10
12.7-13.5
≥1180
≥91.5
Qualified for finishing and semi-finishing machining of refractory steel, high manganese steel and common steel.
YW2
M20
12.5-13.2
≥1350
≥90.5
Qualified for semi-finishing machining of refractory steel, high manganese steel and common steel.
Zhuzhou Better Tungsten Carbide Co., Ltd is located in Zhuzhou City, Hunan Province, China, where is the largest tungsten carbide producing area in China.
Our main products inclue: Tungsten carbide rods, carbide strips, carbide dies and bushes, tungsten carbide roll rings, carbide disc cutters, carbide end mill cutters, carbidestud and pins, tungsten water jet cutters, precision tools, tungsten carbide grits and powder, welding rods, ceramet inserts, PCD and CBN tools, non-standard and deep-processing products and so on. We also provide very good quality of boron carbide, silicon carbide nozzles.
Our company gathered the professional staff members for designing, producing and saling. Our workers are well trained and experienced. Our team is honest, positive, keeping promise, working hard and carefully. We sincerely hope we can provide our clients with good quality, moderate price together with professional service. We have got ISO9001: 2008 certificate, with advanced equipment, test facilities and professional employees. We strictly carry on ISO9001: 2008 requirements to guarantee the quality.
We have good relations with many factories in tungsten carbide line. We have large stock to keep the fastest delivery. In this way, Our products are 100% quality guaranteed and delivery fast.
